Connecting to Video Equipment

(such as a Laser Disc player, a DVD player, a DSS,or a Video Camera)
I
Read SAFETY GUIDELINES (
before proceeding to these steps:
1) Choose an appropriate site and install the product on a level table where the stand is
secure.
• Install the monitor to have ready access to a power socket available.
2) Make sure that the video equipment's power switch is off.
3) Interconnect the signal input terminal on the monitor rear panel and the video equipment's
signal output terminal to each other using an commercially available video cable.
4) Insert one end of the power cable included into the rear-panel power cable connector and
the other end into a power socket.
5) Turn on the monitor, then the video equipment's to make sure that a display image
appears on the monitor screen.
• For instructions on turning on the monitor and adjusting its display images, see
"Operating Instructions" (
Speaker (R)
Power cable
connector
Power
AUDIO IN AUDIO IN
cable
P
R L/MONO R L/MONO
To audio/
video input
terminals
• If video equipment with an S video output terminal is used, cabling by the S video cable is
recommended to provide finer video quality. (If an S video input terminal and a video input
terminal connect to the monitor at the same time, S video input would govern.)
• If video equipment is equipped with component video output (Y, P
connect to the corresponding color (Y, P
monitor.
• If the VIDEO1 OUT terminal is connected to an external monitor with a 75 Ohm terminal, it
is possible to view the same image as on the main unit. If an external monitor is not being
used, the cable must be removed from the VIDEO OUT terminal. The image will appear
white as saturation level is reached.
NOTE : Y to Y, P -C
B B
to
I
to ).
9
19
Monitor rear panel
VIDEO 2 VIDEO 1
COMPONENT COMPOSITE S
/C P /C Y IN OUT IN
R R B B
To component
input terminals
P
B,
to P , P -C to P .
B R R R
) carefully to ensure maximum safety
VII
Speaker (L)
Video equipment
(such as a video disc player,
a DVD player, and a video camera)
Use if the
video
equipment
has an
S video
input terminal
) input jack on the component input of the
R
External Monitor
VIDEO 1
COMPOSITE S
IN OUT IN
To component
input terminals
P or Y, C C ), please
B, R B, R
7
