17 Technical Information
How to Connect the Open Collector Inputs of the Controller
Tab. 5
PIN N.
1
2
3
4
5
6
7
8
9
Note that the vent valve can also be controlled by means of the serial
NOTE
connection
A serial communication kit with a serial cable and the Navigation
software is available (optional).
240/282
Signal characteristics and use
SIGNAL NAME
+5 V (OUT)
TX (RS232)
RX (RS232)
A+ (RS422 Optional)
GND
A + (RS485)
B - (RS422 Optional)
B - (RS485)
RESERVED
