6. System Components

CleanSpace Respirator is a complete respiratory protection system. In addition some combinations of components have
been approved for use in some explosive atmospheres. Not all of the components shown below have been approved for use
1A PAF-0064 Half Mask – Small, EX
1B PAF-0062 Half Mask – Medium, EX
1C PAF-0063 Half Mask – Large, EX
1D PAF-0033 Half Mask – Small
1E PAF-1010 Half Mask – Medium
1F PAF-0027 Half Mask – Large
1G pAF-1014 Full Face Mask
in explosive atmospheres. See Approvals below for details.
2A PAF-0035 Filter P3 TM3 P SL R Standard
2B PAF-0037 Filter P3 TM3 P SL R High Capacity
2C PAF-0046 Combined filter A1P3 (AU)
2D PAF-0047 Combined filter ABE1P3 (AU)
2E PAF-0050 Combine filter A1TM3 P SL R (EU)
2F PAF-0051 Combine filter ABE1TM3 P SL R (EU)
3A PAF-0042, 65 & 72 Filter Cover 2, EX & Ultra
3B PAF-0038 Filter Adaptor (large case filters)
Figure 1 - System Components
4A PAF-0073 Head Harness- Half mask
5 PAF-0034, 60, 70 Power Unit 2, EX & Ultra
7B PAF-0040, 66 Battery Chargers 2,Ultra & EX
5
USER INSTRUCTIONS
4B PAF-1016 Head Harness – Full Face
6A PAF-1012 Neck support (small)
6B PAF-1013 Neck Support (Large)
7A PAF-1005 Flow Test Cap
7C PAF-1009 Seal Check cap
