STEPS FOR TESTING THE FLOW RATE:

Make sure nothing is blocking the Flow Test Cap or the filter inlet. Place CleanSpace Respirator flat on a table or other
support.

Press and release the button marked "Flow Test"

CleanSpace Respirator automatically runs the Flow Test. The motor will run fast and air will be discharged from the Flow
Test Cap.

After two (2) seconds CleanSpace Respirator reports the result of the test using the LEDs on the keypad. Use the table
below to interpret the LEDs.
LIGHTS
3 LEDs:
2 LEDs:
1 LED:
ALL LEDs FLASH

Remove the yellow Flow Test Cap and store for later use.
STEP 4 - DON THE RESPIRATOR WITH FULL FACE MASK
NOTE: Please read STEP 4 all the way through before beginning to don CleanSpace Respirator
Locate your blower, your mask and your neck support.
Fit a Neck Support
When CleanSpace Respirator is used with a mask the neck support is for comfort only and does not form part of the seal.
Nevertheless you may find that comfort is improved by selecting the right size of neck support as explained below. In
particular, if your job involves a lot of vigorous movement, selecting the right size neck support and adjusting the machine
correctly will stabilise the respirator against your neck and reduce distracting movement.
FITTING THE NECK SUPPORT
CleanSpace Respirator comes supplied with two neck
supports:

PAF-1012 NECK SUPPORT SMALL

PAF-1013 NECK SUPPORT LARGE
Select a neck support. PAF-1012 is more suited to smaller
faces while PAF-1013 fits people with larger faces.
The neck support has keyhole openings at each end which
snap over buttons on the respirator case. Place the neck
support in position against the buttons and then press
firmly backwards (towards the respirator) to engage the
buttons in the keyholes.
Meaning
PASS (Excellent: flow >180 l/min)
PASS (Good)
PASS (Acceptable)
FAIL (Flow <120 l/min)
Do not use CleanSpace Respirator until a new filter has been fitted and / or battery charged
and the test has been repeated with a PASS result.
Reset the respirator by pressing the Power button. Fully charge the battery and / or replace the
filter. Repeat the flow test. If filter is new and battery fully charged but CleanSpace Respirator
fails the test, contact PAFtec and do not use until it has been evaluated
