Taurus ERGO X Montage- Und Bedienungsanleitung Seite 38

A66 Steel-Fan Cover-L
A67 Steel-Fan Cover-R
A68 Decoration Cover-L
A69 Decoration Cover-R
A70 Chain Cover(L)
A71 Chain Cover(R)
A72 Sensor Housing
A73 Screw
A74 Screw
A75 Screw M6*20Mm
A76 Steel
A77 Pad
A78 Brake Pad
A79 Spring
A80 Screw M6*10Mm
A81 Sensor Wire 150Mm
A82 Plastic Cover
B Front Stabilizer
B1 End Cap
B2 Wheel
B3 Screw M8*40
B4 Nut M8
B5 Adjusting End Cap
B6 Screw
C Rear Stabilizer
C1 End Cap Φ101.6
C2 Nut
C3 Knob Φ50
C4 Step Mat
38
1 C5 Screw
1 D1 Swing Handlebar (L)
1 D2 Swing Handlebar (R)
1 D5 Bearing 6202Zz
1 D6 Screw M5*8Mm
1 D7 C Clip S40
1 D8 Bearing 6203Zz
6 D9 End Cap
6 D10 Bearing 6003 Zz
1 D11 Spring Washer Φ17
4 E Console Tube
1 E1 Sensor Wire 450Mm
2 E2 End Cap
1 F Console
2 F1 Screw
1 G1 Foot Support
1 G2 End Cap
1 H1 Pedal-L
2 H2 Pedal-R
2 I Metal Fixing Plate
2 J1 Screw M8*60Mm
2 J2 Screw M8*30Mm
2 J3 Spacer Ring
4 J4 Nut M8
1 J5 Screw M6*12Mm
2 J6 Screw M10*20Mm
2 J7 Screw M6*8Mm
2 J8 Spacer Ring
1
4
1
1
2
4
2
2
2
2
2
1
1
1
1
4
2
2
1
2
1
1
2
2
6
8
2
2
ERGO X
