The Bionic L ink is suitable for fitting on either the right or left side.
INFORMATION
The BionicLink 60X3 requires no battery as the power is supplied from the knee joint battery.
5 Applying the Bionic Link 60X3 (Fig. 1 to Fig. 4)
1. P lug the Radio Adapter Cable into Bionic L ink (you do not have to remove the plug anymore).
2. Place Velcro® into slit on backside of Bionic L ink (velcro facing outwards) (Fig.1)
3. Snap Bionic L ink onto C-Leg/C-Leg compact Knee Joint (Fig. 2)
INFORMATION
Positon Bionic L ink 60X3 in a left sided fitting medially, in a right sided fitting laterally on the
Knee Joint.
4. Loop free end of Velcro® around the Knee Joint, pull it through the plastic ring, pull tight and
fasten shut (Fig. 3).
5. Plug the Radio Adapter Cable into the Knee Joint's jack (Fig. 4).
6. The lit up LED signalizes that the Bionic L ink is ready for operation.
6 Start-up
1. S et-up connection between Bionic L ink and PC. For details regarding set-up of communica-
tion and of a serial communication with Bluetooth®, please refer to your Bluetooth® documen-
tation.
2. Enter PIN.
INFORMATION
PIN code needed for communication set-up: 2534
3. Start the adjustment software on the computer (from C-Soft version 1.0 upwards).
4. Make the necessary adjustments (Remind the amputee to stand safe and still during the ad-
justments).
5. Data transmission to Bionic L ink will function properly with visual contact within a 10 meter
perimeter of the PC.
During data transfer the LED will blink.
6. After the adjustment, remove BionicLink and wireless adapter cable. Replace the protective
plug on the knee joint.
INFORMATION
If the knee joint is outside the transmitter range or the transmission route is shielded (e.g. by
steel or armored concrete), the connection can be interrupted.
The message "Transmission interrupted" will appear on your screen.
