before fitting the cassette (Pic. 8).
- Using the torque wrench, tighten the lock ring supplied
with the cassettes onto the freehub body (Pic. 10).
CAUTION!
Strictly follow the instructions provided by the cassette ma-
nufacturer with regard to specific installation techniques,
the need for additional spacers and torque specifications.
NOTE: please contact your dealer if you have questions or
are unable to install the cassette. The warranty does not
cover any DAMAGE to the bicycle and/or Drivo in the event
of incorrect installation.
- Drivo includes the correct 5mm diameter quick release
adapter for dropout spacing ranging from 130mm (5,1
inches) to 135mm (5,3 inches). Therefore, on bikes with
130-135mm (5,1 to 5,3 inches) dropout spacing, insert
the left dropout adapter (Ref. G) (Pic. 10). Please consult
the paragraph on page 39 for bikes with 12mm diameter
(0.47 in.) x and 142mm (5,6 in.) thru-axle spacing.
- Place the bicycle chain onto the smallest sprocket of
Drivo (Pic 12).

ASSEMBLING YOUR DRIVO

- Loosen the bike's rear brake and place the chain on the
smallest rear sprocket and the largest front chainring. Re-
move the quick release from the rear wheel.
- Insert the quick release and the dropout adapter (Rif.C)
on the Drivo sprocket cassette (Pic. 11).
- Place the bicycle chain onto the smallest sprocket of
Drivo (Pic 12).
- Fully fit the bicycle's rear dropouts onto Drivo's cassette
(Pic. 13), paying careful attention to the correct internal or
external position, based on the type of bicycle:
- External triangle adapter (Rif. C) for road and time trial
bikes (130mm triangle) (Pic.14).
- Internal triangle adapter (Rif. C) for mountain bikes
(135mm triangle) (Pic. 15).
NOTE: the knurled side of the triangle adapter (Rif. C) must
be facing the bicycle dropout.
INSTALLING THE SPROCKET CASSETTE ON
THE DRIVO FOR Ø12 L=142 mm CHAIN-
STAYS
- For bikes with rear thru-axle you need to change the
sleeve set in the chainstay spindle:
1) If it's inserted, remove the left adapter (Ref. G) and
unscrew the right adapter for 130-135 mm chainstays
(Pic.16);
2) Screw the right adapter to its end (Ref. E) and insert the
left adapter (Ref. F) for 142 mm chainstays (Pic.17);
3) Attach the spacer (Ref. E) with the 17mm key (11/16
inches) with a 5Nm tightening torque (44 in-lbs). Use a
medium strength, oil-tolerant threadlocker to lock the nut
on the spindle;
4) Loosen the rear brake of the bicycle and place the chain
on the smallest sprocket of the rear wheel and the front
chainring. Remove the thru-axle from the rear wheel.
5) Position the bicycle's rear dropouts on the axle of the
sprocket cassette of the Drivo.
6) Insert the thru-axle on the Drivo sprocket cassette shaft.
(Pic. 11)
7) Make sure the bicycle is safely positioned on the Drivo
and lock the thru-axle with a strong push. The pressure
should make the bike dropouts remain locked onto the
structure of the Drivo.
Make sure the bike is stable by pushing and pulling the
top tube of the frame and the saddle. Should the bike still
be moving a little on the Drivo, use more force to lock the
thru-axle.
WARNING: both feet support three different types of wheel
height; rotate the foot (Pic. 18) facing downwards based
on your wheel dimension:
1) mountain bikes with 27,5'' wheel dimension (Pic. 19);
2) road bikes with 28'' or MTB 26'' wheel dimension (Pic.
20) ;
3) mountain bikes with 29'' wheel dimension (Pic. 21).
- Start pedalling. Ride very slowly at first and increase
your speed gradually until you become familiar with the
features of Drivo.

CONNECTIONS

NOTE: DO NOT PLUG THE USB DONGLE INTO THE PC
BEFORE INSTALLING THE REAL SOFTWARE.
- Drivo has an electronic motherboard that is powered via
a standard power supply adapter (included).
- Connect the power supply to the grid and the jack to
the proper connector on the back of the Drivo. A small
vibration indicates that the system is booting up to its initial
position. This operation might last up to 15 seconds.
Hang the power supply cable on the dedicated hanger
(Pics 22 and 23).
- The Drivo compliance with EU laws (see "Declaration of
conformity", page 112) may be voided if a different char-
ger from the original is used.

REMOVING THE BICYCLE

- Shift the bicycle chain on the smallest cassette sprocket
of Drivo and of the smallest front chainring of the bicycle.
- Open up the quick release (or remove the thru-axle) and
remove the bicycle from the Drivo.
- For transportation, or simply to reduce clutter when not
