If a PIR intruder alarm if detected in the Night mode and the
detector switches back to Day mode, the red LED starts
flashing to indicate an alarm in memory.
The alarm memory is reset by switching the detector to Night
mode.

DIP switch setting

SW 1: When to signal AM (anti-masking) or TF (technical
fault) output
On: Signals AM or TF only when the system is in Day mode
(default). Note that SW 5 must be in the OFF position for this
functionality to be enabled.
Off: Always signals AM or TF during Day and Night mode.
SW 2: AM sensitivity
On: Selects a higher level of AM sensitivity. AM relay reacts
within 6 seconds.
Off: Selects the standard AM sensitivity. AM relay reacts within
12 seconds (default).
SW 3: Resetting the AM/TF output
The system will only reset an AM alarm if it has ensured that
the cause of the AM alarm has been removed. If the AM
circuitry cannot return to its original reference levels, then
either the detector is still masked or possibly has been
damaged. The owner should then visually check that the
detector is still fully functional.
On: Resets the AM or TF status 40 seconds after a PIR alarm.
Off: Resets the AM or TF status after a PIR alarm when the
system is in Day and Walk Test status. The yellow LED will
blink quickly. When the system is in Night status, the yellow
LED will turn off and the system is reset (default).
SW 4: Signaling AM or TF output
On: Signals AM on both the AM and Alarm relays. Signals TF
on the AM relay only (EN 50131).
Off: Signals AM and TF on the AM relay (default).
SW 5: Setting LEDs
On: Enables both LEDs on the detector at all times (default).
Off: Puts both LEDs under the control of the Walk Test and
Day/Night input. This activates the memory feature of the
detector.

LED indication

PIR Red LED Alarm relay
Start up Closed
Low voltage Open (Alarm)
PIR intruder Open (Alarm)
alarm
PIR/AM Red Yellow
LED LED
Start up
4 / 10
To reset
Automatically after 25 s
Apply correct voltage
Automatically after 3 s
Alarm AM To reset
relay relay
Closed Closed Automatically
after 60 s
PIR/AM Red Yellow
LED LED
Low voltage
PIR intruder
alarm
Latched PIR
(Memory)
AM alarm
After AM
reset
Technical
fault
* Depends on the setting of the DIP switch SW4.
Continuously on Normal blinking (1 Hz)

Specifications

Detector
Signal processing
Range
Optical
Memory
Input power
Peak-to-peak ripple
Detector start-up time
Normal current consumption
Current consumption in
alarm
Maximum current
consumption
Mounting height
Dead zones
Target speed range
Alarm (NC) / Tamper relay
characteristic
Pry-off tamper (not evaluated
by UL/cUL)
AM relay characteristic
Alarm time
Operating temperature
Dimensions (H x W x D)
Relative humidity
Weight
IP/IK rating

Regulatory information

Manufacturer PLACED ON THE MARKET BY:
UTC Fire & Security Americas Corporation, Inc.
3211 Progress Drive, Lincolnton, NC, 28092, USA
AUTHORIZED EU REPRESENTATIVE:
UTC Fire & Security B.V.
Kelvinstraat 7, 6003 DH Weert, Netherlands
P/N 146575999-1 (ML) • REV B • ISS 07MAR19
Alarm AM To reset
relay relay
Open Open Apply correct
(Alarm) (Alarm) voltage
Open Automatically
(Alarm) after 3 s
Switch to Night
mode
Open* Open See DIP
(Alarm) (Alarm) switch 3
Switch to Night
mode
Open Do a successful
(Alarm) walk test
Fast (4 Hz)
EV1012-D EV1012AM-D
PIR PIR + AM
DSP
12 m
9 high-density mirror curtains
No Yes
9 to 15 VDC (12 V nominal)
2 V (at 12 V )
25 s 60 s
4.4 mA 10 mA
1.2 mA 3.8 mA
11 mA 24 mA
1.8 m to 3.0 m
0.9 m at minimum mounting height
30 cm/s to 3 m/s 20 cm/s to 3 m/s
80 mA 80 mA
30 V , resistive 30 V
N/A Onboard (yes)
—
80 mA at 30 V
max.
3 s
−10 to +55°C
108 × 60 × 46 mm
95% max. noncondensing
120 g 128 g
IP30 IK02
