EN: Installation Sheet
Introduction
The EV1000-D series includes models EV1012-D and
EV1012AM-D. These detectors have a patented mirror, pyro,
and signal processing technology.
Installation guidelines
The technology used in these detectors resists false alarm
hazards. However, avoid potential causes of instability such as
(see Figure 1):
•
Direct sunlight on the detector
•
Strong draughts onto the detector
•
Heat sources within the detector field of view
•
Large animals within the detector field of view
•
Obscuring the detector field of view with large objects,
such as furniture
•
Objects within 50 cm of the anti-masking (AM) detector
•
Installing two detectors facing each other and less than
50 cm apart
Installing the detector
Figure 7
(1) Standard connection (factory
default)
(2) Dual loop connection
CP Control panel
To install the detector:
1. Lift off the custom insert and remove the screw
(see Figure 2, item 1).
2. Using a screwdriver, carefully prise open the detector (see
Figure 2, items 2 and 3).
3. Fix the base to the wall between 1.8 m and 3.0 m from the
floor. For flat mounting use a minimum of two screws (DIN
7998) in positions A. For corner-mounting use screws in
positions B or C (Figure 3). To install a pry-off tamper, use
position A or B.
4. Wire the detector (see Figures 3 and 7).
5. Select the desired jumper and DIP switch settings (see
Figure 5). See "Jumper settings" below for more
information.
6. Remove the blinders and add the stickers, if required (see
Figure 6 for an example).
For ceiling-mount applications that require a 90° coverage,
7.
use the SB01 swivel-mount bracket.
8. Close the cover.
9. Insert the screw and place the custom insert.
For EN 50131 Grade 3 installations, do not use mounting
position C.
Jumper settings
See Figure 5 for the jumper locations in the detector.
P/N 146575999-1 (ML) • REV B • ISS 07MAR19
WT Walk test
AM Antimasking
D/N Day/night
Rtest Remote test
J1: Not used
J2: PIR enabling the LED
On: Enables the detector LED at all times (default).
Off: Puts the LED under control of the WT (walktest) input. If
the WT input is connected to GND (terminal 1), the red LED
goes on for 3 seconds when a PIR intruder alarm is detected.
If the WT input is connected to +12 V (terminal 2) or floating,
the red LED is disabled.
J3 and J4: Dual loop setting
This sets the alarm and tamper relays. It allows you to connect
the detector to any control panel. Use jumpers 3 and 4. See
Figure 7.
J5: D/N mode (Day/Night) or Rtest (remote test) setting
Use this jumper to set terminal 8 to either D/N or Rtest. UTC
Fire & Security recommends that you use D/N to manage the
AM/TF activation when required. Use Rtest to test the detector
from the control panel. The detector will activate the Alarm
relay if the test result is positive, and the AM relay if the test
result is negative.
On: Terminal 8 = D/N (default).
Off: Terminal 8 = Remote test.
J6: Polarity setting of the control voltage (CV)
On (factory default):
•
The detector is in Day mode (system disarmed) when the
D/N input is connected to GND (terminal 1)
•
The detector is in Night mode (system armed) when the
D/N input is connected to +12 V (terminal 2)
•
The detector is in Walk Test Off mode (LEDs are disabled)
when the WT input is connected to GND (terminal 1)
•
The detector is on Walk Test On mode (LEDs are
enabled) when the WT input is connected to +12 V
(terminal 2)
Off:
•
The detector is in Day mode (system disarmed) when the
D/N input is connected to +12 V (screw terminal 2).
•
The detector is in Night mode (system armed) when the
D/N input is connected to GND (terminal 1).
•
The detector is in Walk Test Off mode (LEDs are disabled)
when the WT input is connected to +12 V (terminal 2).
•
The detector is on Walk Test On mode (LEDs are
enabled) when the WT input is connected to GND
(terminal 1).
D/N and WT functionality
The D/N input:
•
Controls the LED functionality together with the WT input.
•
Resets the alarm memory
•
Controls the AM relay functionality during the NIGHT
mode together with SW1.
The WT input controls the LED functionality together with the
D/N input.
When the detector is in the Day mode and Walk Test On
mode, the LEDs of the detector can be activated. See "LED
indication" on page 4 for more information.
During the Night mode the LEDs are always switched off.
