7. Interface
Command
Control mode
:pa <-110 ... 110>
:pd
:pr <-1100 ... 11000>
:ps <-10 ... 110>
:pu
:saz<0 | 1>
:sbr<0 ... 1>
:sbu<0 ... 1>
:sci<n | u | r>
sdb <0 ... 100>
:spu <0 ... 9>
:ssl <d | e>
WIKA operating instructions, model CPC2000
Answer function
Increase the set pressure demand by x percent
-110 ... +110 --> change in set pressure demand in %
Decrease set pressure demand by currently-set step size in %
(Step DOWN).
Adjust the current working and measuring ranges
-1,100 ... +11,000 --> new measuring range in 0.01 % FS
Percentage set pressure demand -10 ... +110 --> set pressure
demand in %
Increase set pressure demand by currently-set step size in %
(Step UP).
Set auto zero (in measuring and control modes)
0 --> of
1 --> on
Set baud rate RS-232
0 --> 1200
1 --> 2400
2 --> 4800
3 --> 9600
4 --> 14400
Set baud rate USB
0 --> 1200
1 --> 2400
2 --> 4800
3 --> 9600
4 --> 14400
Select active interface
Set communication interface
n --> Interface of
u --> USB active
r --> RS-232 active
Display brightness
0 ... 100 --> brightness in %
Pressure unit
0 --> Pa
1 --> hPa
2 --> ka
3 --> mbar
4 --> bar
5 --> Torr
System language
d = German
e = English
5 --> 19200
6 --> 28800
7 --> 38400
8 --> 56000
9 --> 57600
5 --> 19200
6 --> 28800
7 --> 38400
8 --> 56000
9 --> 57600
6 --> mmHg
7 --> inHg
8 --> psi
9 --> mmH O
2
10 --> inH O
2
