6. Commissioning, operation

6.3 Operating mode 'AUTO'

In AUTO mode, a pressure profle can be stored. This is especially useful when multiple
pressure sensors or pressure switches are to be calibrated with the same values. The
GB
mode also enables a defned profle to be traversed several times in succession.
Setting
Press the MENU button. Confrm the menu item MODE with the SELECT button and
■
press the
For the AUTO mode, the submenu points RANGE, UNIT and STEPS are not relevant.
■
Go to the SETTINGS menu item with the
■
SELECT button. The submenu item zero point adjustment is not relevant.
In the submenu, go to the AUTO mode item with the UP/DOWN buttons and confrm
■
with SELECT.
RANGE: Pressure range that will be covered
■
UNIT: Pressure unit
■
STEPS: The number of steps which will be taken to increase and decrease the
■
pressure. These increments are calculated by the controller itself.
In the submenu point, CONFIGURATION 1, further settings can be defned for the AUTO
mode.
20
/ button until AUTO appears. Confrm with SELECT.
/ buttons and confrm with the
WIKA operating instructions, model CPC2000
