6. Commissioning, operation
In the menu, go to the UNIT item with the
■
confrm with SELECT.
Press the MENU button in order to exit the menu.
■
SETTINGS submenu:
■
Go to the SETTINGS menu item with the
■
In the submenu, go to the zero point adjustment item and confrm with SELECT.
■
Under the point, AUTO-ZERO, the automatic zero point adjustment for the MEAS
■
mode can be activated or deactivated.
Operation
On leaving the menu, the zero point of the internal sensor is adjusted, dependent upon
the setting. The instrument then begins to measure the subsequent pressures.
Operating mode
Battery status
Using the ZERO button in MEAS mode, the instrument's zero point can be compensated
at any time.
CAUTION!
If the connected pressure should exceed the permissible highest loading
(125 %), the internal sensor will be closed of using a magnetic valve.
The display will then show ERROR. Using the SELECT button, the
instrument can be closed of and opened up freely.
WIKA operating instructions, model CPC2000
/
Full scale value
Set point in % of the full scale value
button, select the pressure unit and
/ button, confrm with SELECT.
Pressure unit
Measured value
