The ideal spacing between the housing edge of
the window / door contact and the magnet
contact should be 5 mm (see figure 5).
5.2.2

Adhesive strip or screw mounting

You can use
• the double-sided adhesive strip or
• countersunk head screws
to fix the device to the window/door frame.
Do not yet assemble the magnetic contact before
screw mounting.
Adhesive strip mounting
For mounting the device using the adhesive strips, please
proceed as follows:
• Attach the large double-sided adhesive strip to
the back side of the bracket (A) (see figure 6) and
press the device to the desired position on the
window.
• Place the magnet in the bracket at the back side
and place the back side into the housing of the
magnetic contact (see figure 7).
When using the spacer (E), fasten the smaller ad-
hesive strip at the back side of the spacer (see
figure 6) and attach it to the desired position on
the window. Afterwards, place the magnet con-
tact on to the spacer.
Start-up
