Start-up
5.2
Mounting
Read this entire section before starting to mount
the device.
5.2.1
Selecting a suitable mounting location
•
Select a window or door for mounting the
window / door contact.
•
Fix one part of the window / door contact
(magnetic contact (I) or electronic unit (K)) to the
moving part (door or window wing), the other
one at the stationary part (frame) of the window
or door (see figure 5).
•
Fasten the window / door contact on the side of
the window or door where the handle is located,
in the upper third of the window/door frame (see
figure 5) (for fastening see "5.2.2 Adhesive strip or
screw mounting" on page 45).
•
The magnetic contact can be mounted in a
horizontal or vertical way, left or right to the
electronic unit of the window / door contact.
The electronic unit and the magnetic contact
should be mounted at the same height. Since a
spacer (E) can be used for the magnetic contact
to raise it, the electronic unit must be mounted
on the higher part of the window.
44
