Start-up
5.1.1

Direct pairing with a Homematic IP device

You can connect the Homematic IP Window and
Door Contact with magnet (HmIP-SWDM) to a
Homematic IP Radiator Thermostat – basic
(HmIP-eTRV-B).
Please make sure you maintain a distance of at
least 50 cm between the devices.
You can cancel the pairing procedure by briefly
pressing the system button (C) again. This will be
indicated by the device LED (C) lighting up red.
To connect the device with another Homematic IP device,
the pairing mode of both devices has to be activated. To
do this, please proceed as follows:
Loosen the electronic unit (B) from the bracket
•
(A) by pushing it upwards and removing it to the
front (see figure 2).
• Remove the insulation strip from the battery
compartment (F) of the window / door contact.
• Press and hold down the system button (C) for
at least 4 seconds to activate the teach-in mode
(see figure 3). The device LED (C) starts to flash
orange. Pairing mode remains activated for 3
minutes.
• Press and hold down the system button of the
device you want to connect (e.g. the Homemat-
