del día de su suministro, quedando excluidas
todas las manipulaciones o daños ocasionados
por manejos inadecuados o por desgaste natural
de la máquina.
Para cualquier reparación dirigirse al servicio ofi cial
de asistencia VIRUTEX S.A.
VIRUTEX se reserva el derecho de modifi car sus
productos sin previo aviso.
English
FR160P-FRE160P ROUTER
(ILUSTRATIONS IN PAGE 29)
IMPORTANT
CAUTION. Read these OPERATING INSTRUC-
TIONS and the attached GENERAL SAFETY
INSTRUCTIONS LEAFLET carefully before using
the machine. Make sure you have understood them
before operating the machine for the fi rst time.
Keep both sets of instructions for any future
queries.
1. TECHNICAL DATA
FR160P
Universal motor.........................................50/60 Hz
Input power................................................1,500 W
No-load speed.......................................25,000/min
Equivalent measured continuos
acoustic pressue level A..........................91 dB(A)
Acoustic pressure level.........................104 dB(A)
Normal level of vibrations (hand-arm).......<2,5 m/s
Chuck collet Ø.............................................12 mm
Routing depth............................................0-60 mm
Revolving depth
gauge.......................6-position depth adjustment
Weight...........................................................5.4 Kg
FRE160P
Universal motor..........................................
Input power................................................
No-load speed.....................................
Equivalent measured continuos
acoustic pressue level A...........................
A c ou sti c pre ssu r e le vel. . .. . .. . .. . .. . .. . .. . ..
Normal level of vibrations (hand-arm)........
Chuck collet Ø.............................................
Routing depth............................................
Revolving depth
gauge.......................6-position depth adjustment
Weight...........................................................

2. OPERATION RANGE

The router is an electric appliance used for routing
6
wood and plastics. It is also very convenient for
trimming edges, cutting out of knots, copy cutting,
rebate cutting, making of frames and engraving.
Together with parallel guide, template followers,
compasses and profi le cutters, it is an exceedingly
useful appliance.
3. SAFETY INSTRUCTIONS FOR
MACHINE OPERATION
WARNING! Before using the router, carefully read
the GENERAL SAFETY INSTRUCTIONS LEAFLET
included with the machine documentation.
- When changing tools or carrying out any other
operation near the cutting head, take your hand
from the on/off lever and unplug the machine from
the mains.
- Use safety goggles when working with the
router.
- Always guide the router with both hands, using
the machine's two handles.
- When you have fi nished working, disconnect
the motor and release the base before leaving
the router.
- Always place the router on its base on a fl at,
clean surface.
- Always start the router by using the main on/off
lever.
- Make sure that the router cannot be accidentally
knocked over.
- Always use cutter bits with the appropriate shaft
diameter for the chuck collet and the router speed
to be used.
- The specifi cations of the cutter bits in the VIRU-
TEX range are especially suitable for use with
2
this router; we recommend using cutter bits from
the wide VIRUTEX range or bits with the same
specifi cations.

4. STANDARD EQUIPMENT

The box contains the following items:
- FR160P - FRE160P router
- A/f service key: 24
- Ø 19 mm template guide for 26-mm pitch
loops.
- Lateral fence assembly
- Dust collector connection
- Operating instructions and miscellaneous do-
cumentation.
- 6022387 Cutter bit 12 to 8 adaptor
- 6022388 Cutter bit 12 to 6 adaptor
5. STARTING UP THE MACHINE
This tool has an operating switch A (Fig. 1) in the
handle, enabling the machine to be turned on and
off without releasing it.
To prevent the machine from starting up accidenta-
