Jacuzzi® authorized service centres offer single-piece packages of
perfumed sticks, to be used as explained below.
■
To remove the dispenser from its seat, follow the steps indi-
cated. Then insert the perfumed sticks or drops of your favourite
essence and close the dispenser. Press the dispenser until it fas-
tens completely.
We recommend cutting the stick into two pieces, placing one in each
dispenser (the shower enclosure has two steam nozzles, located on
the sides of the column).
■
Press the button "I/O" (1): the LED begins to flash.
■
After about 2 minutes (the LED begins to flash more slowly)
the water begins to heat up. After a very short time, steam be-
gins to come out of the nozzles located alongside the columns
Note: Condensate might come out of the nozzle; however, this will
stop once the temperature is stable.
■
This function ends after 40 minutes, but it can be switched off
at any time by pressing the button "I/O".
3
2b
■
The recommended length of the steam bath is about 20 minutes,
even if the total time set by the manufacturer is 40 minutes. You can
choose to enter the shower enclosure when steam production be-
gins, or after a certain time, when the temperature and the amount
of steam inside the shower enclosure have increased.
When you finish the steam bath, do not turn off the main
switch for at least 2 minutes, as this will prevent the washing
and emptying of the boiler (

SCALE-REMOVAL CYCLE

To troubleshoot problems caused by lime scale in the boiler, the
shower enclosure is equipped with a function, which, thanks to the
cleaning action of a special product, cleans the boiler of any scale
deposits.
The cycle lasts about
the "alarm" function but not the steam bath; however, the "water jet
2a
functions" are still available.
■
Prepare the scale-removal liquid by pouring the contents of
the bottle into about 0.75 litres of water. Mix well to blend the
mixture.
■
Making sure that the shower enclosure is powered, hold down
the button (3) for about 3 seconds: the LED begins to flash, indi-
cating the start of the cleaning cycle.
■
Unscrew the cap of the scale-removal nozzle as shown in the
figure (detail 1), insert the conduit provided (detail 2) and pour
the liquid in the opening.
15 15
).
: during this time, it is possible to use
-
