SFA R300 Installationshinweise Seite 7

UK
The numbers refer to the explanatory diagrams.
Fully illustrated step by step
instructions are downloadable
on www.saniflo.co.uk
1 DESCRIPTION
The SANICUBIC Pro is a lifting station
designed to evacuate effluent from small
®
private or commercial units.
Please comply with all the installation and
maintenance specifications set out in these
instructions, and especially the information
marked with the following signs:
" " Failure to comply with this
information could entail safety
hazards for personnel,
" " Information warning of the presence
of an electrical hazard,
" " Instructions only for qualified
professional specialists,
"WARNING" Failure to comply with this
information could affect the normal
operation of the equipment.
Please contact our Customer service for
further information.
SANICUBIC OPERATING
PRINCIPLE
Pro contains 2 separate
pumps. Each of the pumps is fitted with a
SANICUBIC ®
high-performance maceration system.
The 2 pumps operate alternately. In the
event of inflow overload, both motors run
at the same time (or if one of the pumps is
faulty, the other one takes over).
The SANICUBIC Pro tank is fitted with
2 dip tubes; one tube controls motor
®
operation, and the other one controls the
alarm system.
- Long pickup tube (normal operation):
as soon as the waste water level in the
tank reaches the triggering point in the
long tube, the pumping system starts up.
- Short pickup tube (inflow overload
operation): if the waste water level in the
tank reaches the upper point, a contact is
closed, and the auxiliary pumping system
is triggered. The contact also sets off an
audible and visual alarm. The general
alarm LED on the SANICUBIC
control panel switches to red. The system
sends a high-frequency malfunction signal
to the remote alarm unit. The
Pro is fitted with a remote
alarm module that transmits a visible and
SANICUBIC ®
audible alarm (HF link).
2 LIST OF PARTS SUPPLIED
3 DIMENSIONS
Type
4 TECHNICAL DATA SANICUBIC
Maximum discharge head
Voltage
Frequency
Volume
Maximum power input
Maximum current input
Electrical classification
Ave water temp for optimum performance 35°C
Maximum temperature (intermittent)
Protection index
Net weight (including accessories)
*Hot water drain cycles from dishwashers or washing machines
5 FIELD OF APPLICATION
Household waste water (the combined
inputs must not exceed 80% of those
shown in the graph
6 PERFORMANCE CURVE
Example: Pump P1 is operating normally.
It discharges 160 l/min at a pumping
height of 5 m. If pump P1 shows any
signs of weakness or if the waste water
inflow is too great, pump P2 starts up. The
output is then increased to about 275
l/min, until the situation returns to normal.
7 RATIO OF HEIGHT/LENGTH
FOR DISCHARGE
8 INSTALLATION
The SANICUBIC
in compliance with standard EN12056.
The equipment must be commissioned
and maintained by a qualified professional
specialist.
Please refer to installation standard
EN 12056.
1- Attention: the space in which the 8a REGULATIONS
must be large enough to leave at least
SANICUBIC
600 mm of working room around and
above the unit to facilitate such
maintenance work as may be required.
There must be sufficient lighting, and it
must be sufficiently well ventilated and
protected from freezing.
2- Isolating valves (not supplied) must
be fitted on waste inlets (especially
the 110mm inlets) and on the
discharge to ensure that any
service/maintenance may be carried
3- The discharge pipe must be fitted so as out safely).
to avoid all back flow from the drainage
system (see the examples in drawing
). Back flow can be avoided by
installing an anti-back flow riser
8g
reaching a high point above the
maximum back flow level.
Comment: In the absence of local
® Pro
information to the contrary, the
maximum back flow level corresponds
to street level (roadway, pavements,
etc.). Continue the discharge pipework
after the anti-backflow riser, using a
larger diameter pipe.
4- If the Sanicubic is installed in a space
such as a pit for example, we would
recommend the fitting of a bilge pump
in case of flooding.
5- The lifting station must be vented with
an outlet at roof level.
6- The lifting station must be fixed to the
R300
PRO
®
floor (see paragraph
11 m
220-240V
50 Hz
CONNECTING THE DISCHARGE
8b
47 l
PIPE
Remove the end cover or covers from the
3000 w
back of the unit (cf.
13 A
As each pump is fitted with a macerator
system, an ND50 mm discharge pipe can
I
be used.
70°C*
The discharge bend is at the centre of the
IP67
unit, at the back (cf.
30 kg
to connect it to the riser pipe and fix it
in place with the collars.
D
).
6
Pro must be installed
®
Pro is to be installed
®
).
8h
).
1
8g
). Use the sleeve
8b
Each pump in the SANICUBIC
is fitted with check valves.
See paragraph regarding control
valves and back flow.
8a
8c CONNECTING SANITARY
EQUIPMENT TO THE LOWER
INLETS
If you want to install a shower or
a bath at the same level as the
®
SANICUBIC Pro, you must make
sure that the upper parts of the plu-
gholes on the sanitary equipment are
at least 250 mm above the lower inlets.
CONNECTING THE INLETS ND 40/50
8d
Lower inlets (cf. 8d 1 )
• Cut off the end of the ND 50 inlet with a
Upper inlets (cf. 2 )
8d
saw
• Cut the sleeve to suit the pipe
diameter: ND 40 or ND 50 (cf.
D
• Fix the sleeve on the inlet and on the
pipe, using the collars.
D
CONNECTING THE ND 100/110 INLET
8e
1- Remove the plug from the side inlet.
Lower inlets (cf. 8e 1 )
2- Fix the sleeve in place using the
collar. .
F
3- Fully insert the ND 100/110 tube in the J
other end of the sleeve and fix it in
place using the other collar.
1- Cut off the upper end of the ND 100 Upper inlets (cf. 8e 2 )
inlet with a saw.
2- Fix the sleeve in place using the
collar .
F
3- Fully insert the ND 100/110 tube in the J
other end of the sleeve and fix it in
place using the other collar
8f CONNECTING THE VENT
One of the upper ND50 inlets must be
used for the vent. The vent pipe must be
fitted up to roof level.
Cut off the end of the one of the ND 50
inlets with a saw.
Then fix the sleeve in place using the
collar .
D
C
Fully insert the ND 50 tube in the other
end of the sleeve and fix it in place using
the other collar .
C
WARNING: Do NOT fit air admittance
valve on the top of the air vent pipe. The
vent must be an open vent or the unit will
not operate.
DRAINING
The SANICUBIC 8g Pro unit is fitted with
2 plugs ( ).
®
8g 1
Disconnect the unit from the power
supply.
1- Unclip the cover.
To drain the unit
2- Remove one of the 2 plugs.
3- Insert a wet utility vacuum cleaner pipe
to drain the unit. The port diameter is
40 mm.
4- When the unit has been drained, put
the plug and then the cover back in
place.
Pro unit
®
)
3
8d
.
J
.
J
