9 DIGITAL PRESSURE GAUGE FEATURES & FUNCTIONS (continued)
9.2 SWITCHING THE GAUGE ON AND OFF
TO SWITCH ON: Press
followed by the MIN and MAX range in MPa.
TO SWITCH OFF: Press
released.
Note: When the digital pressure gauge is switched off, "OFF" is permanently displayed.
AUTOMATIC SWITCH OFF: The gauge has a timer function and can be set to switch off automatically
after 1, 5 or 20 minutes of inactivity. The gauge default setting is NONE.
MENU
1 Press until TIMER is displayed followed by
2 Press or
MAX
MENU
3 Press to select the setting required

9.3 SELECTING THE UNITS

The gauge can display readings in MPa (Megapascals) or PSI (Pounds per Square Inch)
1 Press until UNITS is displayed followed by
MENU
2 Press or
MAX
MENU
3 Press to select the units required
www.elcometer.com
. The gauge displays the version of software fitted (e.g. 1.04.03 IDENT)
and hold for a second. The gauge will switch off when the button is
to toggle between the options; NONE, 1 MIN, 5 MIN, 20 MIN
to toggle between MPA and PSI
to select
to select
