8 AFTER TEST

8.1 ANALOGUE PRESSURE GAUGE
1 Fully unwind the crank handle and coarse adjustment screw (anti-clockwise) to decrease the
pressure to zero
2 Pull up the quick connect coupling to release the dolly
8.2 DIGITAL PRESSURE GAUGE
1 Fully unwind the crank handle and coarse adjustment screw (anti-clockwise) to decrease the
pressure to zero
2 Pull up the quick connect coupling to release the dolly
3 Press to release the 'Max Hold'
MAX
4 Press again to zero the gauge and reset 'Max Hold'
MAX
Note: Failure to release the 'Max Hold' and zero the gauge before each adhesion test will result in an invalid adhesion
measure.
9 DIGITAL PRESSURE GAUGE FEATURES & FUNCTIONS
Read this section if you are using an Elcometer 506 Adhesion Tester fitted with a digital pressure gauge.

9.1 FITTING THE BATTERIES

1 Peel the protective rubber boot forward to expose the battery compartment cover at the rear of the gauge
2 Rotate the battery compartment cover anti-clockwise to the 'unlock' position
3 Identify correct polarity and fit 2 x AA alkaline dry batteries
4 Replace battery compartment cover and rotate clockwise to the 'lock' position
5 Replace protective rubber boot taking care not to damage the front panel of the display.
The battery symbol at the bottom right hand side of the display indicates the battery condition.
