F a u l t D i a g n o s i s
S Y M P T O M P O S S I B L E C A U S E
More than one Air leak
operation of the Insufficient air pressure
trigger needed to Lack of lubrication
place fastener Worn or broken jaws
Low oil level or air present in oil
Build up of dirt inside nose assembly
Tool will not grip Worn or broken jaws
stem of fastener Build up of dirt inside nose assembly
Loose jaw housing
Weak or broken spring in nose assembly
Incorrect component in nose assembly
Rotary valve incorrectly adjusted
Jaws will not Build up of dirt inside nose assembly
release broken Jaw housing, nose tip or nose casing
stem of fastener not properly seated
Weak or broken spring in nose assembly
Air or oil leak
Low oil level or air present in oil
Cannot feed Broken stems jammed inside tool
next fastener
Rotary valve incorrectly adjusted
Slow cycle Lack of lubrication
Low air pressure
Build up of dirt inside nose assembly
Tool fails to operate No air pressure
Damaged trigger valve 40
Restricted air supply
Loose stem collector
Fastener fails to Insufficient air pressure
break Fastener outside tool capability
Low oil level or air present in oil
* Pages 12 to 13 if a swivel head is used instead of a nose assembly.
† Page 13 if a swivel head is used instead of a nose assembly.
Item numbers in bold refer to the general assembly drawings and parts lists pages 22-25.
Other symptoms or failures should be reported to your local Avdel authorised distributor or repair centre.
