S e r v i c i n g t h e To o l
H e a d A s s e m b l y
Unscrew retaining nut 26 and pull off stem collector assembly, items 18, 20, 21, 22, 23, 24, 25 and 'O' ring 19.
Pull off stem collector adaptor 15.
Using the 'T' spanner* remove end cap 27 together with seal 17 'O' ring 16 and lip seal 28.
Remove spring 29 and spring seat 54.
Loosen locknut 3 with a spanner* then unscrew jaw spreader housing 1 and 'O' ring 2.
Remove locknut 3 together with 'O' ring 43 and 7 lip seal.
Push head piston 8 to the rear and out of head assembly 4 taking care not to damage the cylinder bore.
Using circlip pliers* remove seal retainer 30. Push lip seal 9 to the rear and out of head assembly 4 taking care again not to damage
the cylinder bore.
Remove seal housing 6 and lip seal 53.
Assemble in reverse order to dismantling noting the following points:
Place lip seal 9 onto the insertion rod* ensuring correct orientation. Push the guide tube* into the head of the tool and push the
insertion rod* with the seal into place through the guide tube*. Pull the insertion rod* out then the guide tube.
The chamfered edge of seal retainer 30 must face forward with the gap at the bottom.
After fitting seals 12, 52 and 13 onto the piston ensuring correct orientation, lubricate the cylinder bore and place the piston sleeve*
into the back of head assembly 4. Slide the bullet* onto the threaded part of piston 8 and push the piston with the seals through the
piston sleeve* as far as it will go. Slide the bullet* off the piston and remove the piston sleeve.
Jaw spreader housing 1 must be fully tightened onto head piston 8 before tightening locknut 3 against it.
Use Loctite 932 when reassembling retaining nut 26.
Tr i g g e r
Using the 2 millimetre diameter pin punch*, drive trigger pin 42 out and lift off trigger 41.
Unscrew trigger valve 40 using the trigger valve extractor*.
Assemble in reverse order to dismantling.
Item numbers in bold refer to the general assembly drawings and parts lists pages 22-25.
* Item included in the G2-s service kit. For complete list see page 18.
E n g l i s h
19
