Disassembling the product before carrying out the reprocessing procedure
►
Disassemble the product immediately after use, as described in the respective instructions for use.
►
With insufflation valve 2: Open stopcock 2a.
Preparations at the place of use
►
If applicable, rinse non-visible surfaces preferably with deionized water, with a disposable syringe for example.
►
Remove any visible surgical residues to the extent possible with a damp, lint-free cloth.
►
Transport the dry product in a sealed waste container for cleaning and disinfection within 6 hours.
Preparation before cleaning
►
Dismantle the product prior to cleaning, see Disassembling.
Cleaning/disinfection
Product-specific safety notes on the reprocessing procedure
Damage to the product due to inappropriate cleaning/disinfecting agents and/or
excessive temperatures!
►
Use cleaning and disinfecting agents according to the manufacturer's instruc-
tions which
CAUTION
– be approved for plastic material (thermoplastics, silicon) and high-grade
steel,
– do not attack softeners (e.g. in silicone).
►
Observe specifications regarding concentration, temperature and exposure
time.
►
Do not exceed the maximum permitted cleaning temperature of 94 °C.
►
Use suitable cleaning/disinfecting agents if the product is put away in a wet condition. To prevent foam forma-
tion and reduced effectiveness of the process chemicals: Prior to mechanical cleaning and disinfection, rinse the
product thoroughly with running water.
►
Carry out ultrasound cleaning:
– as an effective mechanical supplement to manual cleaning/disinfecting.
– as a pre-cleaning procedure for products with encrusted residues, in preparation for mechanical cleaning/
disinfecting.
– as an integrated mechanical support measure for mechanical cleaning/disinfecting.
– for additional cleaning of products with residues left after mechanical cleaning/disinfecting.
Validated cleaning and disinfection procedure
Validated procedure Specific requirements
■
Manual cleaning with immersion
Cleaning brush, e.g. TA
disinfection
no. 007747
■
20 ml disposable syringe
■
Drying phase: Use a lint-free
cloth or medical compressed air
■
Manual pre-cleaning with brush
Cleaning brush, e.g. TA
and subsequent mechanical alka-
no. 007747
line cleaning and thermal disinfec-
■
20 ml disposable syringe
tion
■
Place the product in a tray that
is suitable for cleaning (avoid-
ing rinsing blind spots).
■
With insufflation valve 2: Con-
nect insufflation stopcock 2 or
Luer valve directly to the spe-
cial connector at the injector
carriage.
Manual cleaning/disinfection
►
Prior to manual disinfecting, allow water to drip off for a sufficient length of time to prevent dilution of the dis-
infecting solution.
►
After manual cleaning/disinfection, check visible surfaces visually for residues.
►
Repeat the cleaning /disinfection process if necessary.
Manual cleaning with immersion disinfection
Phase Step T
[°C/°F]
I Disinfecting RT (cold)
cleaning
II Intermediate RT (cold)
rinse
III Disinfection RT (cold)
IV Final rinse RT (cold)
V Drying RT
D–W: Drinking water
FD–W: Fully desalinated water (demineralized, low microbiological contamination: drinking water quality
at least)
RT: Room temperature
*Recommended: BBraun Stabimed
►
Note the information on appropriate cleaning brushes and disposable syringes, see Validated cleaning and dis-
infection procedure.
Phase I
►
Fully immerse the product in the cleaning/disinfectant for at least 15 min. Ensure that all accessible surfaces are
moistened.
►
Clean the product with a suitable cleaning brush in the solution until all discernible residues have been removed
from the surface.
►
If applicable, brush through non-visible surfaces with an appropriate cleaning brush for at least 1 min.
Reference
Chapter Manual cleaning/disinfec-
tion and sub-chapter:
■
Chapter Manual cleaning with
immersion disinfection
Chapter Mechanical cleaning/dis-
infection with manual pre-clean-
ing and sub-chapter:
■
Chapter Manual pre-cleaning
with a brush
■
Chapter Mechanical alkaline
cleaning and thermal disinfect-
ing
t Conc. Water Chemical
[%] quality
[min]
>15 2 D–W Aldehyde-free, phenol-free,
and QUAT-free concentrate,
pH ~ 9*
1 - D–W -
15 2 D–W Aldehyde-free, phenol-free,
and QUAT-free concentrate,
pH ~ 9*
1 - FD-W -
- - - -
►
Mobilize non-rigid components, such as set screws, links, etc. during cleaning.
►
Thoroughly rinse through these components with the cleaning disinfectant solution (at least five times), using a
disposable syringe.
Phase II
►
Rinse/flush the product thoroughly (all accessible surfaces) under running water.
►
Mobilize non-rigid components, such as set screws, joints, etc. during rinsing.
►
Drain any remaining water fully.
Phase III
►
Fully immerse the product in the disinfectant solution.
►
Mobilize non-rigid components, such as set screws, joints, etc. during rinsing.
►
Rinse lumens at least 5 times at the beginning of the exposure time using an appropriate disposable syringe.
Ensure that all accessible surfaces are moistened.
Phase IV
►
Rinse/flush the product thoroughly (all accessible surfaces).
►
Mobilize non-rigid components, such as set screws, joints, etc. during final rinse.
►
Rinse lumens with an appropriate disposable syringe at least five times.
►
Drain any remaining water fully.
Phase V
►
Dry the product in the drying phase with suitable equipment (e.g. cloth, compressed air), see Validated cleaning
and disinfection procedure.
Mechanical cleaning/disinfection with manual pre-cleaning
Note
The cleaning and disinfection device must be of tested and approved effectiveness (e.g. FDA approval or CE mark
according to DIN EN ISO 15883).
Note
The cleaning and disinfection device used for processing must be serviced and checked at regular intervals.
Manual pre-cleaning with a brush
Phase Step T
[°C/°F]
I Disinfec- RT (cold)
tant
cleaning
II Rinsing RT (cold)
D–W: Drinking water
RT: Room temperature
*Recommended: BBraun Stabimed
►
Note the information on appropriate cleaning brushes and disposable syringes, see Validated cleaning and dis-
infection procedure.
Phase I
►
Fully immerse the product in the cleaning/disinfectant for at least 15 min. Ensure that all accessible surfaces are
moistened.
►
Clean the product with a suitable cleaning brush in the solution until all discernible residues have been removed
from the surface.
►
If applicable, brush through non-visible surfaces with an appropriate cleaning brush for at least 1 min.
►
Mobilize non-rigid components, such as set screws, links, etc. during cleaning.
►
Thoroughly rinse through these components with the cleaning disinfectant solution (at least five times), using a
disposable syringe.
Phase II
►
Rinse/flush the product thoroughly (all accessible surfaces) under running water.
►
Mobilize non-rigid components, such as set screws, joints, etc. during rinsing.
Mechanical alkaline cleaning and thermal disinfecting
Machine type: single-chamber cleaning/disinfection device without ultrasound
Phase Step T
[°C/°F]
I Prerinse <25/77
II Cleaning 55/131
III Intermediate >10/50
rinse
IV Thermal disin- 90/194
fecting
V Drying -
D–W: Drinking water
FD–W: Fully desalinated water (demineralized, low microbiological contamination: drinking water quality
at least)
*Recommended: BBraun Helimatic Cleaner alkaline
►
Check visible surfaces for residues after mechanical cleaning/disinfecting.
Inspection, maintenance and checks
Damage (metal seizure/friction corrosion) to the product caused by insufficient
lubrication!
►
Prior to function checks, lubricate moving parts (e.g. joints, pusher compo-
nents and threaded rods) with maintenance oil suitable for the respective ster-
CAUTION
ilization process (e.g. for steam sterilization: Aesculap STERILIT® I oil spray
JG600 or STERILIT® I drip lubricator JG598).
►
Allow the product to cool down to room temperature.
►
After each complete cleaning, disinfecting and drying cycle, check that the product is dry, clean, operational, and
free of damage (e.g. broken insulation or corroded, loose, bent, broken, cracked, worn, or fractured components).
t Conc. Water Chemical
[%] quality
[min]
>15 2 D–W Aldehyde-free, phenol-free,
and QUAT-free concentrate,
pH ~ 9*
1 - D–W -
t Water Chemical
quality
[min]
3 D–W -
■
10 FD-W
Concentrate, alkaline:
– pH = 13
– <5 % anionic surfactant
■
0.5 % working solution
– pH = 11*
1 FD-W -
5 FD-W -
- - According to the program for cleaning
and disinfection device
