Danger!
risk of electric shock!
• Before reaching into the system, switch off the power supply and secure to prevent reactivation!
• Observe applicable accident prevention and safety regulations for electrical equipment!
Procedure:
→
The DIP switches can be accessed by unscrewing the body casing (stainless steel).
→
Set the DIP switches
→
Close the device.
Settings of the Devicenet address
MAC ID - Medium Access Control Identifier:
[DIP 1=off=0 / DIP 1=on=1 / MAC ID=DIP 1*2
dip 1
[20=1]
off
on
off
...
off
on
Table 14: Settings of the DeviceNet address
Setting the baudrate
Adjusting the control head to the baudrate of the network.
dip 7
off
on
off
on
Table 15: Setting the baudrate
please note:
if the settings are changed by actuating the dip switches, this change will not take effect until the
device is restarted.
For a restart
• briefly disconnect the control head from the power supply and reconnect or
• switch the power supply off/on or
• transmit an appropriate reset message.
42
according to the following tables.
dip 2 dip 3
[21=2] [22=4]
off off
off off
on off
... ...
on on
on on
dip 8 Baudrate
off 125 kbaud
off 250 kbaud
on 500 kbaud
on not permitted
english
0 +DIP 2*2 1 +...+DIP 6*2 5 ]
dip 4 dip 5
[23=8] [24=16]
off off
off off
off off
... ...
on on
on on
Type 8691
Device-Net
dip 6
Mac id
[25=32]
off 0
off 1
off 2
... ...
on 62
on 63
