MindPrint T.R.I.O.

13. Technical Specifications

13.1 Mechanical Data

Dimensions (w x d x h)
Device: 260 mm x 195 mm x 66 mm
Power unit: 65 mm x 128 mm x 52 mm
Weight
Device: 1550 g
Power unit: 650 g

13.2 Electrical Data

Mains input
Power unit
Primary: 230 V AC/ 100 V AC/ 117 V AC
Secondary: 15 V 1700 mA

13.3 Inputs and outputs

MIC IN:
Port: XLR ( 1 = ground; 2 = +; 3 = -)
Input type: Electronically balanced & floating
Input impedance: 10 kOhm
Min. input level: -34 dBu (GAIN at peak setting,
+12 dBu Speaker Out)
-51 dBu (GAIN at peak setting,
0 dBu Speaker Out)
Max. input level: 4 dBu (GAIN no higher than 12 o'clock)
Gain control range: -74...-14 dBu = 60 dB @SEND, -40 dBu
input with compressor
Gain control range: -74...-10 dBu = 64 dB @SEND -40 dBu
input without compressor
Peak amplification: 30 dB without compressor
Phantom power: +48 VDC switchable
INSTR. IN:
Port: 1/4" jack ( tip = +; ring = -);
MIC disabled when in use
Input type: unbalanced
Input impedance: 1 MegOhm
Min. input level: -25 dBu (GAIN at peak setting,
+12 dBu Speaker Out, - 3 dBFS)
-39.5 dBu
0 dBu Speaker Out, -14 dBFS)
20
(GAIN at peak setting,
Max. input level: +14 dBu
-18 dBu
Gain control range: - ...19 dB (-10 dBu to SEND , -29 dBu
input, without compressor)
Peak amplification: 19 dB
LINE IN:
Port: 1/4" jack ( tip = +; ring = - )
Input type: unbalanced
Input impedance: 51 kOhm
Min. input level: 0 dBu (+12 dBu Speaker Out)
-6 dBu (+6 dBu Speaker Out, -1 dBFS)
Max. input level: + 21 dB
AUX IN:
Port: RCA ( tip = +; ring = - )
Input type: unbalanced
Input impedance: 51 kOhm
Min. input level: 0 dBu (+12 dBu Speaker Out)
-6 dBu (+6 dBu Speaker Out, -1dBFS)
Max. input level: + 12 dB
DAW IN:
Port: RCA ( tip = +; ring = - )
Input type: unbalanced
Input impedance: 7 kOhm
Min. input level: 0 dBu (+12 dBu Speaker Out)
Gain control range: - ...6 dB (0 dB at 12 o'clock)
Max. input level: + 10 dB (GAIN knob at 12 o'clock)
DAW OUT:
Port: RCA ( tip = +; ring = -)
Input type: unbalanced
Max. output imp.: 7 kOhm
Output level: 0 dBu (0 dBu LINE IN)
Gain control range: - ...6 dB (0 dB at 12 o'clock)
SPEAKERS OUT:
Port: SPEAKER A 1/4" jack ( tip = +; ring = -)
SPEAKER B
SPEAKER C
Input type: unbalanced
Output impedance: 47 Ohm
Output level: 1
2 dBu (0 dBu LINE IN, MASTER Gain
maxed, MONITOR Gain maxed)
(GAIN at 12 o'clock)
(GAIN at peak setting)
RCA ( tip = +; ring = -)
RCA ( tip = +; ring = -)
