5. Technical data

AC motor
Rating
Idle speed n
0
Carbide saw blade
Number of teeth
Weight
Dust extraction connector
For use as a crosscut and miter saw
Swiveling range
Miter cut
Saw width at 90°
Saw width at 45° (turntable)
Saw width at 45° (angle)
Saw width at 2 x 45° (double miter cut) 40 x 105 mm
For use as a bench circular saw
Size of bench
Max. cutting height
Height adjustment
Tilting saw blade

6. Before starting

Pull the power plug before performing any
adjusting, conversion and assembly work.
The machine has to be set up where it can stand
securely.
All covers and safety devices have to be properly
fitted before the machine is switched on.
It must be possible for the blade to run freely.
When working with wood that has been
processed before, watch out for foreign bodies
such as nails or screws, etc.
Before you press the ON/OFF switch check that
the saw blade is fitted correctly and that moving
parts move easily.
Before you connect the machine to the mains
supply make sure that the data on the model
plate are identical to the mains data.
22
23.06.2008
9:42 Uhr
6.1 Installing and transporting the machine
(Fig. 3 – 6)
1. Lift the machine out of the packaging and place it
230 V ~ 50 Hz
on a flat surface with the saw bench (2) at the
1800 W
bottom (Fig. 3).
4200 rpm
2. Unfold the base frame (6). To do this, undo the
knurled nuts (21), unfold the legs (6) and secure
Ø 250 x Ø 30 x 3.0 mm
them with the knurled nuts (21) (Fig. 4).
60
3. Turn the machine over and place it on the base
35 kg
frame (6). If the surface is not flat, the machine
Ø 36 mm
can be made secure using the two adjustable
feet (22) (Fig. 5).
4. Screw the two cable hooks (23) to the left-hand
side of the machine (Fig. 6).
Up to 45° to the left
5. The front legs (6) can be extended to transport
+45° / 0° / -45°
the machine. The machine can now be
transported like a wheelbarrow using the front
65 x 155 / 23 x 200 mm
legs (6) as handles.
65 x 155 / 23 x 200 mm
40 x 155 mm

7. Operation

7.1 Crosscut and miter saw
540 x 500 mm
7.1.1 Conversion work for use as a crosscut and
70 mm
0 - 70 mm infinite
1. The saw is set up for use as a bench circular saw.
2. If necessary remove the angle and parallel stop
0° - 45° to the right
(see 7.2.2) and the saw blade guard (see
7.2.1/11).
3. Turn the knurled screw (Fig. 1 / Item 13) as far as
possible clockwise to move the saw blade to its
lowest position.
4. Install the chip box (20). First attach it to the two
lugs than secure it to the saw bench (2) using the
screw (Fig. 7).
5. Push the lever (Fig. 8 / Item 24) and carefully
swing the saw over (Fig. 8 – 10).
Important. When you swing the saw bench, there
is a risk of suffering crush injuries to your hands
and finger. Only touch the saw bench at the front
and rear when swinging it. Do not reach between
the saw bench and the side parts. Hold the
bench securely as you swing it. Ensure that the
lever engages fully again after you have swung
the saw bench and that the bench is locked into
position.
6. Push the machine head (17) downwards using
the handle (Fig. 1 / Item 16) while pulling out the
locking pin (Fig. 16 / Item 25) for the height
adjustment and turning it clockwise through an
angle of 90° (Fig. 11-12).
Important. The integral resetting springs will
automatically lift the machine head. Do not
immediately let go of the handle (Fig. 1 / Item 16)
after cutting, but allow the machine head (17) to
Seite 22
miter saw
