The device must only be connected with an electric installation carried out in compliance with the IEC-
standards. The electric installation must be equipped with a Residual Current Device (RCD) with a maximum
fault current of 30 mA.
Lighting effects must not be connected to dimming-packs.

OPERATION

After you connected the spot to the mains, the EUROLITE LED KLS-200 RGB DMX starts running and the
display lights up.
The device has two operating modes. It can be operated in sound controlled or in DMX-controlled mode.
You can choose the desired mode via the buttons MENU, UP and DOWN:
When the display shows A*** , you can choose the desired DMX addresse via the UP or DOWN buttons.
When the display shows *512, the device is in DMX mode. To switch to sound controlled mode, press the
DOWN button.
When the display shows *SND, the device is in sound controlled mode. To switch to DMX mode, press the
DOWN button.
When the display shows S***, you can choose the desired speed of the internal programs. Default is 51; for
increasing speed press the DOWN button, for decreasing speed press the UP button.

DMX-CONTROLLED OPERATION

You can control the spots individually via your DMX-controller.

DMX-protocol

Channel 1 – Internal Programs, Auto Mode, Sound Controlled Mode
Value:
000 – 009
010 – 029
030 – 049
050 – 069
070 – 089
090 – 109
110 – 129
130 – 149
150 – 169
170 – 189
190 – 209
210 – 229
230 – 249
250 – 255
Channel 2 – Master Dimmer
Value:
000 – 009
010 - 255
Function:
Off
Program 1
Program 2
Program 3
Program 4
Program 5
Program 6
Program 7
Program 8
Program 9
Program 10
Program 11
Auto Mode: Internal Programs
Sound Controlled Mode
Function:
Off
Dimming from 0 – 100%
