Procedure:
Step 1: Open the fuseholder on the rear panel with a fitting screwdriver.
Step 2: Remove the old fuse from the fuseholder.
Step 3: Install the new fuse in the fuseholder.
Step 4: Replace the fuseholder in the housing.
Should you need any spare parts, please use genuine parts.
If the power supply cable of this device becomes damaged, it has to be replaced by a special power supply
cable available at your dealer.
Should you have further questions, please contact your dealer.
TECHNICAL SPECIFICATIONS
Power supply:
Power consumption:
Number of DMX channels:
DMX-512 connection:
Number of 10mm LEDs:
Beam angle:
Sound-control:
Maximum ambient temperature T
Maximum housing temperature T
Min.distance from flammable surfaces:
Min.distance to lighted object:
Fuse:
Dimensions (LxWxH):
Weight:
Accessories:
Foot switch for LED KLS-200
EUROLITE STV-40S Lighting stand, Steel
EUROLITE STV-40A Lighting stand, Alu
Please note: Every information is subject to change without prior notice. 29.09.2008 ©
230 V AC, 50 Hz ~
70 W
15
3-pin XLR
432
25°
via built-in microphone
:
45° C
a
(steady state):
60° C
B
0.50 m
0.10 m
F 2 A, 250V
1110 x 55 x 295 mm
8 kg
No.
42109710
59006996
59007001
20/20
00037747.DOC, Version 1.1
