Safety and Quick Start Guide Druck DPI612
DPI612: Pressure Calibrator (Figure 1)
DPI612-PFX (pFlex Pneumatic Calibrator):
-950 mbar to 20 bar (-13.5 to 300 psi)
DPI612-PFP (pFlexPro Pneumatic Calibrator):
-950 mbar to 100 bar (-13.5 to 1500 psi)
DPI612-HFP (hFlexPro Hydraulic Calibrator):
0 to 1000 bar (0 to 15000 psi)
Operating Temperature Range:
-10 °C to +50 °C (+14 °F to +122 °F)
+10 °C to +30 °C (optimized calibration specification)
0 °C – 40 °C with optional mains power supply
Storage Temperature: -20 °C to +70 °C (-4 °F to +158 °F)
Humidity: 0 to 90 % Relative Humidity (RH)
Non-condensing
Power Supply: 100 – 260 V +/-10 %, 50 / 60 Hz AC, Output DC V=5 A,
1.6 A, CATII of IEC60364-4-443
Altitude: Up to 2000 m
Batteries (Rechargeable): LiIon 14.1Wh GE Part number: CC3800GE
Nominal voltage 3.7V 3800mAh Charge temperature: 0° to 40°C (32°
to 104°F) Discharge temperature: -10° to 60°C (14° to 140°F). Note: For
best battery performance, keep the temperature less than 60°C
(140°F).
Batteries (Non-rechargeable): 8 × AA Alkaline
Pressure Leak rates:
DPI612-PFX = 0.01 bar/min at 20 bar
DPI612-PFP = 0.02 bar/min at 100 bar
DPI612-HFP = 1 bar/min at 1000 bar
Vacuum Leak rates:
DPI612-PFX = 0.005 bar/min at 95% Vacuum
DPI612-PFP = 0.005 bar/min at 95% Vacuum
DPI612-HFP = n/a
Recommended Pressure Modules (PM620)
DPI612-PFX: 2 to 20bar (3 to 300 psi)
DPI612-PFP: 20 to 100bar (300 to 1500psi)
DPI612-HFP: 200 to 1000bar (3000 to 15000psi)
[EN] English – 109M0089
