7.1.2

Replacing the oil filter cartridge

Read all indicated in Section 6.1 before starting any maintenance jobs.
Replace the oil filter cartridge after the first 500 hours of use then every 2500/3000 hours and in
any event each time the oil is changed.
Open the rear panel.
Disassemble filter cartridge 1, using a chain spanner and replace with a new one.
Lubricate the sealing gasket before screwing the filter cartridge tight.
Manually tighten the new filter cartridge.
7.1.3 Replacing the filter cartridge of the oil separator
Read all indicated in Section 6.1 before starting any maintenance jobs.
Open the side panel to gain access to inside the compressor.
Disassemble filter cartridge 2, using a chain spanner and replace with a new one.
Lubricate the sealing gasket before screwing the filter cartridge tight.
Manually tighten the new filter cartridge.
