4.4.2 Connecting to the pneumatic mains

Connect the compressor to the pneumatic mains using the fitting 1.
Use hosing with a greater or same diameter as the compressor outlet.

4.4.3 Connecting to the pneumatic mains (compressor a on the ground)

Connect the compressor to the pneumatic mains using the fitting 1.
Use hosing with a greater or same diameter as the compressor outlet.
Install two ball taps with capacity suitable for the compressor between the compressor and tank
and between the tank and line.
Do not install non-return valves between compressor and tank. The non-return valve is already
installed inside the compressor.
Always use pneumatic hoses for compressed air with the maximum pressure
characteristics and cross section suitable for those of the compressor.
Do not try to repair a faulty hose.
Always use pneumatic hoses for compressed air with the maximum pressure
characteristics and cross section suitable for those of the compressor.
Do not try to repair a faulty hose.
