Display visualization

On
On
On
On
6.3.2

Segnalling leds

LED

6.3.3 Key functions

TEST: Pushed for 3 sec. during normal operation, it allows to activate a condensate drainage
cycle.
SET: When pushed and released during normal operation, it displays the set-point value
(decimal).
When pushed for 10 seconds, it allows to enter the C8 and C9 condensate drain parameters
programming menu (see relevant table).
When pushed after having set new configuration values, it stores the applied modifications.
DOWN: When pushed while setting the set point or the configuration parameters, it decreases
the displayed value of one unit per second, during the first 10 seconds, than of one unit every 0,1
sec.
When pushed for 10 seconds during normal operation, it starts an automatic test cycle of the
controller.
.
UP: When pushed while setting the set point or the configuration parameters, it increases the
displayed value of one unit per second, during the first 10 seconds, than of one unit every 0,1
sec.
ON / OFF: Pushed for 3 seconds, it activates or deactivates the process. When the process is
deactivated, the display shows OFF.
NOTE: when the controller is in OFF position, some parts of the dryer are kept under tension therefore, for
safety purposes, disconnect the electrical power before performing any operation on the machine.
6.3.4 Condensate discharge parameters programming.
Push the SET key for 10 seconds to enter the parameters configuration menu: the display will show
in sequence the set point value, the code of the first modifiable parameter (C8) and its value).
Only if strictly necessary, use the UP and/or DOWN keys to change the displayed parameter value.
Press the SET key to store the previously changed parameter value or to browse the parameters
without changing them.
15 seconds after the last performed operation, the controller will return automatically to the normal
operation mode.
Means the unit is ON with low load;
Means the unit is ON with normal load;
Means the unit is ON with normal-high load;
Means the unit is ON with high load;
STATUS
Blinking
Blinking
ON
ON
ON
78
DESCRIPTION
Compressor energized
Programming mode activated
Condensate drain energized
Speed of the fan = 100%
Speed of the fan < 100%
