must be carried out exclusively by authorised service centres or other qualified centres. The earth
wire of the power supply cable of the compressor must be connected only and exclusively to the
PE pin of the terminal board of the actual compressor. Before replacing the plug of the power
supply cable ensure that the earth wire is connected.
EXTENSION CABLE
Use only extension cables with plug and earth connection. Never use damaged or squashed
extension cables. Ensure that the extension cable is in a good state of wear. When using an
extension cable, ensure that the cross section of the cable is sufficient to convey the current
absorbed by the product to be connected.
If the extension cable is too thin there could be drops in voltage and therefore loss in power and
overheating of the equipment.
The extension cable of the three-phase compressors must have a cross section in proportion with
its length: see table below:
CORRECT CROSS SECTION FOR THE MAXIMIM LENGTH OF 20M
HP
5,5
7,5
10
15
20
Avoid all risks of electrical shocks. Never use the compressor with damaged
electrical cables or extension cables. Regularly check the electrical cables.
Never use the compressor in or near water or near a hazardous area where
electrical shocks may be encountered
ELECTRICAL CONNECTION
The three-phase compressors must be installed by a qualified engineer. The three-phase
compressors are supplied with cable (1) but without plug.
It is advisable to install the connector, magneto thermal switch and fuses near the
compressor (3 m away at the most). The magneto thermal switch and the fuses must have
the characteristics indicated in the table below:
Power HP
4/5,5 Avv. diretto (D.O.L)
4/5,5 Avv. Y- ∆ ∆ ∆ ∆ (Star-Delta)
5,5/7,5
7,5/10
11/15
15/20
KW
4
5,5
7,5
11
15
Rated voltage 380/415V
Magneto thermal switch
Fuse
20A
16A
25A
25A
40A
50A
67
220/240V
50/60 Hz
3 ph
4 mm²
6 mm²
10 mm²
16 mm²
25 mm²
25A
20A
25A
30A
40A
50A
GB
380/415V
50/60 Hz
3 ph
2,5 mm²
2,5 mm²
4 mm²
10 mm²
16 mm²
Rated voltage 220/240V
Magneto thermal switch
Fuse
25A 35A
20A 25A
32A 36A
40A 40A
63A 80A
80A 80A
