Preliminary machine information

2.1

General description

The rotary screw compressor has been specifically designed aiming at minimising maintenance
and labour costs.
The outside cabinet is completely covered in sound-proof and oil-proof panelling thus ensuring its
extended and lasting wear.
The components have been arranged so that all vital parts can be easily reached for maintenance
purposes simply by opening dedicated panels with quick-release locking devices.
The filters and adjustment and safety devices (oil filter, air filter, oil separator filter, regulator valve,
minimum pressure valve, max. pressure safety valve, thermostat, belt tightener, screw
compression unit, pressure switch and oil separator tank emptying and filling taps) are all fitted on
the same side.
The dryer series has been devised with the intention of enclosing a complete compressed air
system in one compact machine. It is indeed connected to a dryer that is capable of supplying dry
air to ensure the perfect and lasting use of the tools.
Note!
Note!
ADVISED LUBRICANTS
Always use oil for turbines with approximately 46 cSt at 40° C and a pour point of at least -8 +10° C.
The flash point must be greater than +200° C.
SCREW OIL
SYNT D46
Use oil with VG32 rating for cold climates and VG68 for tropical climates.
It is advisable to use synthetic oils for very hot and humid climates.
2.2

Intended use

The silent rotary screw compressors have been designed and manufactured exclusively to
produce compressed air.
EVERY OTHER USE, DIFFERENT AND NOT FORESEEN BY ALL INDICATED, RELIEVES THE
MANUFACTURER OF POSSIBLE CONSEQUENT RISKS.
In any event the use of the compressor different to that agreed in the purchase order RELIEVES
THE MANUFACTURER FROM ALL LIABILITIES WITH REGARD TO POSSIBLE MATERIAL
DAMAGE AND PERSONAL INJURY.
The electrical system is not designed for the use in environments subject to explosion or for
flammable products.
The tanks of the compressors have been manufactured in compliance with
the EEC/2009/105 Directive for the European market.
The compressors have been manufactured in compliance with the
EC/2006/42 Directive for the European market.
Check your model on the identification nameplate fitted on the compressor.
It is also indicated in this manual.
NEVER MIX DIFFERENT OIL QUALITIES.
NEVER DIRECT THE JET OF AIR TOWARDS PEOPLE OR ANIMALS. NEVER
USE THE COMPRESSED AIR PRODUCED BY LUBRICATED COMPRESSORS
FOR RESPIRATORY PURPOSES OR IN PRODUCTION PROCESSES WHERE
THE AIR IS IN DIRECT CONTACT WITH FOODSTUFFS UNLESS IT HAS BEEN
FIRST FILTERED AND CONDITIONED FOR SUCH PURPOSE.
