Auxiliary Control Devices - Blitz Monsun Fast Serie Betriebsanleitung

Check hours of duty:
During the normal working of the compressor, regardless with its status except under alarm condition, or
when the diplay shows the text "OFF", the worked hours (loading hours + idle running hours) can be
displayed when the button
The worked hours are divided in two displays: the first one shows the thousands of worked hours, the
second one the worked hours up to 999 (example: worked hours 24563, first display is 024, second display
is 563); pushing the button
If the button is pushed after the second display of the worked hours, the time (in hours) to maintenance
will appear (always displayed in 2 parts as explained above; example: hours to maintenance 1561, first
display is 001, second display is 561)
From this condition, if the button
temperature.
After 10 seconds without any commands the display turns back to the original message.
5.2.2

Auxiliary control devices

1 AIR CIRCUIT PRESSURE CONTROL GAUGE
Ver 5,5 – 10:
Ver 15-20:
is pushed for 4 seconds.
is possible to switch from first to second display.
is pushed again, the display shows the text "OFF" or the air-end
Indicates the air pressure value
Indicates the air pressure value after the non return valve
or min pressure (line pressure or air system pressure).
73
GB
