3.4 GENERAL INFORMATION

Information
Weight (max.)
EN
Diameter
Height

3.5 CONNECTION VALUES

Information
Inlet
Outlet

3.6 PERFORMANCE VALUE

Information
Nominal flow
Inlet pressure (max.)

3.7 OPERATING CONDITIONS

Information
Temperature range
Relative humidity (max.)
4.

SET-UP AND FUNCTION

4.1 OVERVIEW – VPLDSMIR, VPLDSMFR, VSLDSMIR, VSLDSMFR
Value
0,66 (VPLDSMFR, VPLDSMIR)
0,63 (VSLDSMFR, VSLDSMIR)
0,3 (VSLDSMAR, VPLDSMAR)
50
79
Value
¼"
3, 6, 8, 10, 12
1/8", ¼", 3/8", ½"
¼"
3, 6, 8, 10, 12
1/8", ¼", 3/8", ½"
Value
20
300
Value
-20 till +60
98
12/36
Unit
kg
kg
kg
mm
mm
Unit
NPT
fitting mm
fitting inch
NPT
fitting mm
fitting inch
Unit
m /h
3
bar
Unit
°C
%
