Installing to Wall
1
WOOD STUD WALL
Use wall plate (A) as a template, make sure it is level, and mark four mounting holes along the center
lines of the wood studs. Drill four 5/32" (4 mm) dia. holes 2.5" (64 mm) deep. Level wall plate (A) and
attach to wall with four wood screws (C) into stud center. Use of an edge to edge stud finder is highly
recommended. Tighten screws firmly, but do not overtighten.
FLANGE INDICATES TOP
OF MOUNT
WARNING
Do not over tighten screws, or
damage may occur.
A
C
C
A
3 of 33
WOOD STUD
WARNING
Wood screws must
center in stud.
STUD
TOP CUTAWAY VIEW
