Tools Needed for Assembly
• stud finder ("edge to edge" stud
finder is recommended)
• phillips screwdriver
• drill
• 5/32" (4 mm) bit for wood stud wall
• 5/16" (8 mm) bit for concrete and
cinder block
• level
• hammer (optional)
C
( 4 )
M4 x 12 mm
E
( 6 )
M6 x 12 mm
I
( 4 )
M8 x 16 mm
M
( 6 )
ID .219" (5.56 mm)
P
( 4 )
ID .344" (8.74 mm)
Q
( 4 )
M4 x 25 mm
F
( 4 )
M6 x 20 mm
J
( 4 )
M8 x 25 mm
N
( 4 )
R
( 6 )
A
( 1 )
D
M5 x 12 mm
G
( 4 )
M6 x 25 mm
K
( 4 )
T
( 1 )
2 of 33
B
( 4 )
M5 x 25 mm
H
( 4 )
M6 x 30 mm
L
( 4 )
M8 x 40 mm
O
( 4 )
S
( 4 )
ISSUED: 11-02-09 SHEET #: 095-9303-1
( 2 )
