Cord Management
Secure cables to top or bottom of wall mount arm (A) using cable ties (S) as shown.
6
Arm Tension Adjustment
7 If more or less tension is desired in the arm pivot points, do the following:
• To increase tension, turn tension screw(s) clockwise with 3/16" allen wrench.
• To reduce tension, turn tension screw(s) counter-clockwise with 3/16" allen wrench.
NOTE: Do not turn more than half a turn.
S
A
CABLE
TENSION SCREWS
10 of 33
S
ISSUED: 11-02-09 SHEET #: 095-9303-1
