Stainless steel distributor/collector "Multidis SF" for surface heating and cooling systems
EN
Read installation and operating instructions in their entirety before installing the stainless steel distributor/collector!
Installation, initial operation, service and maintenance must only be carried out by qualified tradesmen!
The installation and operating instructions, as well as other valid documents must remain with the user of the system!
Content
1 General information ...........................................10
2 Safety notes ......................................................10
3 Transport, storage and packaging ....................11
4 Technical data ...................................................11
5 Construction and function.................................13
Article
"Multidis SF"
Stainless steel
distributor/collector for
surface heating and
cooling systems, with
flow measuring and
regulating devices
0 - 5 l/min in the flow
distributor
"Multidis SF"
Stainless steel
distributor/collector for
surface heating and
cooling systems, with
regulating inserts in
the flow distributor
"Multidis SH"
Stainless steel
distributor/collector for
radiator connection
"Multidis SF"
Stainless steel
distributor/collector for
surface heating and
cooling systems, with
flow measuring and
regulating devices
1 - 4 l/min in the return
collector
Illustr. 1.1 Summary stainless steel distributors/collectors "Multidis SF" and "Multidis SH"
