oventrop Multidis SF Einbau- Und Betriebsanleitung Für Fachpersonal Seite 12

4.2 Dimensions/Connection sizes
Stainless steel distributor/collector Multidis SF / SH
50
Stellantrieb
G 1
G ⁄
3
L 4
50
G 1
G ⁄
3
4
L
50
G 1
G ⁄
3
4
L
Stellantrieb
50
G 1
G ⁄
3
4
L
Illustr. 4.1 Dimensions/connection sizes stainless steel distributors/collectors "Multidis SF" and "Multidis SH" (see also summary, illustr. 1.1)
Ball valves
Illustr. 4.2 Dimensions ball valves
12
Item no.
32
1405352
1405353
1405354
1405355
1405356
1405357
1405358
1405359
1405360
1405361
1405362
52
32
1405552
1405553
1405554
1405555
1405556
Stellantrieb 1405557
1405558
1405559
1405560
1405561
1405562
52
32
1407152
1407153
1407154
1407155
1407156
1407157
1407158
1407159
1407160
1407161
1407162
52
32
1405152
1405153
1405154
1405155
1405156
1405157
1405158
1405159
1405160
1405161
1405162
52
Item no.
1406383
1406384
1406483
(with thermometer
and red T-handle)
1406583
(with thermometer
and blue T-handle)
1406484
(with thermometer
and red T-handle)
1406584
(with thermometer
and blue T-handle)
Length (L)
Circuits
2 168 mm
3 218 mm
4 268 mm
5 318 mm
6 368 mm
7 418 mm
8 468 mm
9 518 mm
10 568 mm
11 618 mm
12 668 mm
2 168 mm
3 218 mm
4 268 mm
5 318 mm
6 368 mm
7 418 mm
8 468 mm
9 518 mm
10 568 mm
11 618 mm
12 668 mm
2 142 mm
3 192 mm
4 242 mm
5 292 mm
6 342 mm
7 392 mm
8 442 mm
9 492 mm
10 542 mm
11 592 mm
12 642 mm
2 168 mm
3 218 mm
4 268 mm
5 318 mm
6 368 mm
7 418 mm
8 468 mm
9 518 mm
10 568 mm
11 618 mm
12
668 mm
D
Size
DN 20 G ⁄
3
4
DN 25 G 1
DN 20 G ⁄
3
4
DN 20 G ⁄
3
4
DN 25 G 1
DN 25 G 1
Length (L) Length (L)
with ball valve with ball valve
1406383 1406384
223 mm 248 mm
273 mm 298 mm
323 mm 348 mm
373 mm 398 mm
423 mm 448 mm
473 mm 498 mm
523 mm 548 mm
573 mm 598 mm
623 mm 648 mm
673 mm 698 mm
723 mm 748 mm
223 mm
248 mm
273 mm 298 mm
323 mm 348 mm
373 mm 398 mm
423 mm 448 mm
473 mm 498 mm
523 mm 548 mm
573 mm 598 mm
623 mm 648 mm
673 mm 698 mm
723 mm 748 mm
197 mm 222 mm
247 mm 272 mm
297 mm 322 mm
347 mm 372 mm
397 mm 422 mm
447 mm 472 mm
497 mm 522 mm
547 mm 572 mm
597 mm 622 mm
647 mm 672 mm
697 mm 722 mm
223 mm 248 mm
273 mm 298 mm
323 mm 348 mm
373 mm 398 mm
423 mm 448 mm
473 mm 498 mm
523 mm 548 mm
573 mm 598 mm
623 mm 648 mm
673 mm 698 mm
723 mm 748 mm
L1 L2
55 mm 57 mm
80 mm 60 mm
73 mm 60 mm
73 mm 60 mm
85 mm 60 mm
85 mm 60 mm
