E - 24
Multisync LCD
Display
Input Signal
Display Colours
Synchronisation
Range
Resolutions
Supported
Active Display
Area***
2010
51.1 cm (20.1 inch) viewable image size; 1280 x 1024
native resolution (Pixel Count); active matrix;
thin film transistor (TFT); liquid crystal display (LCD);
0.31 mm dot pitch; 150 cd/m
150:1 contrast ratio, typical
Video
Sync Separate sync. TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Composite sync. (Positive/Negative)
(TTL Level)
Sync on Green video (Positive) 0.7
Vp-p and sync. Negative 0.3 Vp-p
Analog Input: Unlimited number of colours
(Depends on the graphics board)
Horizontal 24.0 kHz to 80.0 kHz (Automatically)
Vertical 56.0 Hz to 76.0 Hz (Automatically)
Landscape 720 x 400: VGA text*
640 x 480 at 60 Hz to 76 Hz
800 x 600 at 56 Hz to 76 Hz*
832 x 624 at 75 Hz*
1024 x 768 at 60 Hz to 76 Hz*
1280 x 960 at 60 Hz to 76 Hz
1280 x 1024 at 60 Hz to 76 Hz**
Portrait 480 x 640: at 60Hz to 76Hz
600x 800 at 56 Hz to 76 Hz*
624 x 832 at 75 Hz*
768 x 1024 at 60 Hz to 76 Hz*
960 x 1280 at 60 Hz to 76 Hz*
1024 x 1280 at 60 Hz to 76 Hz**
Landscape Horizontal
Vertical
Portrait Horizontal
Vertical
2
white luminance, typical;
Analog 0.7 Vp-p 75 Ω
399 mm
319 mm
319 mm
399 mm
Specifications
