E - 12
the BNC connector on the monitor labeled H/CS. If you have a
fifth BNC connector (Vertical Sync), connect it to the BNC
connector on the monitor labeled VS (Figure D.1).
Place the 15-pin VGA to BNC and AC adapter cable under
Clip A(Figure D.1A). Then place the 15-pin VGA to BNC and
AC adapter cable under Clip B(Figure D.1B). Replace
connector cover.
NOTE: Incorrect cable connections may result in irregular operation,
damage display quality/components of LCD module and/or shorten the
module's life.
5. Connect one end of the power cord to the AC Adapter and the
other end to the power outlet (Figure E.1).
6. Turn on the monitor (Figure F.1) and the computer.
7. To complete the setup of your MultiSync LCD monitor, use
the following OSM controls:
• Auto Adjust Contrast
• Auto Adjust
• Image Adjust – Fine (MultiSync LCD
NOTE: Manual adjustment of the H/V Position and Image Adjust
H. Size / Fine controls may be required to complete setup of your
MultiSync monitor. For a full description of these OSM controls, refer
to the Controls section of this User's Manual.
NOTE: If you have any problems, please refer to the Troubleshooting
section of this User's Manual.
Please contact your local dealer for information about the Mac Adapter.
Installation
monitor only)
