NEC MultiSync LCD1510V Bedienerhandbuch Seite 168

App. B Preset Signal Timing LCD
App. B Preset Signal Timing LCD
Preset Resolution
1 640 x 400
2 640 x 480
3 640 x 350
4 640 x 400
5 800 x 600
6 800 x 600
7 640 x 480
8 640 x 480
9 640 x 480
10 800 x 600
11 1024 x 768
12 800 x 600
13 1024 x 768
14 1280 x 960
15 1024 x 768
16 1024 x 768
17* 1280 x 1024
18 1280 x 1024
19 1280 x 1024
20 1280 x 960
21 1280 x 1024
22 1280 x1024
* Recommended timing
2010
Vertical
Frequency (Hz) Frequency (kHz) Frequency (MHz)
56.43
59.99
70.09
70.09
56.25
60.32
66.61
72.81
75.00
75.00
60.00
72.19
60.00
60.00
70.07
75.03
60.02
59.93
67.19
75.00
75.03
76.11
2010
Horizontal
24.83
31.47
31.47
31.47
35.16
37.88
35.00
37.86
37.50
46.88
48.36
48.08
52.45
60.00
56.48
60.02
63.98
64.60
71.69
75.00
79.98
81.13
A - 3
Pixel
21.05
25.18
25.18
25.18
36.00
40.00
30.24
31.50
31.50
49.50
65.00
50.00
70.49
108.00
75.00
78.75
108.00
107.50
117.00
126.00
135.00
135.00
