WARNING TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. ALSO, DO NOT USE THIS UNIT'S POLARIZED PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLETS UNLESS THE PRONGS CAN BE FULLY INSERTED. REFRAIN FROM OPENING THE CABINET AS THERE ARE HIGH VOLTAGE COMPONENTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Contents You can register your product online at www.nectech.com/productregistration Your new NEC Technologies MultiSync LCD monitor box* should ® contain the following: • MultiSync LCD Monitor with ™ 1510 tilt/swivel/pivot stand • Power Cord • AC Adapter (#A1240T01) • Video Signal Cable •...
(Figure B.1). Attach the 15-pin mini D-SUB end of the appropriate signal cable to the MultiSync Macintosh cable adapter (Figure B.1). Tighten all screws. NOTE: To obtain the MultiSync Macintosh cable adapter, call NEC Technologies at (800) 820-1230. 3. Connect the 15-pin mini D-SUB of the video signal cable and the AC Adapter cable.
Seite 6
Quick Start cont. 15-pin MAC Adapter mini D-SUB (not included) 15-pin mini D-SUB Figure A.1 Figure B.1 Clip A Power Button Figure C.1 Figure E.1 Figure D.1 Power Cord 78134702.wpc 10/15/99, 1:59 PM...
Controls Quick Start cont. Raise and Lower Monitor Screen The monitor may be raised or lowered in either Portrait or Landscape mode. To raise or lower screen, place hands on each side of the monitor and lift or lower to the desired height (Figure RL.1). Figure RL.1 Screen Rotation Before rotating, the screen must be raised to the highest level to avoid knocking...
Seite 8
Quick Start cont. Tilt and Swivel Grasp both sides of the monitor screen with your hands and adjust the tilt and swivel as desired (Figure TS.1). Remove Monitor Stand for Mounting To prepare the monitor for alternate mount- ing purposes: 1.
Seite 9
Controls OSM™ (On-Screen Manager) control buttons on the front of the monitor function as follows: To access OSM press any of the control buttons ( , ) or the PROCEED or EXIT button. To rotate OSM between Landscape and Portrait modes, press the RESET button. Main Menu Sub-Menu EXIT...
Seite 10
Controls cont.ols Auto Adjust AUTO Automatically adjusts the Image Position, the H. Size and Fine setting. Position Controls H. POSITION Controls Horizontal Image Position within the display area of the LCD. V. POSITION Controls Vertical Image Position within the display area of the LCD. AUTO AUTO Automatically sets the Horizontal and Vertical Image Position within...
Seite 11
Controls cont.ols Information Indicates the current display resolution and frequency setting of the monitor. Control: Operating your monitor at a non-standard EdgeLock ™ timing may cause images to appear darker than normal or have color distortion. Use of the EdgeLock control will adjust images to their normal state.
Recommended Use Safety Precautions and Maintenance FOR OPTIMUM PERFORMANCE, PLEASE NOTE THE FOLLOWING WHEN SETTING UP AND USING THE MULTISYNC LCD COLOR MONITOR: ® • D O NOT OPEN THE MONITOR. There are no user serviceable parts inside and opening or removing covers may expose you to dangerous shock hazards or other risks.
Seite 13
• Do not use primary color blue on a dark background, as it is difficult to see and may produce eye fatigue to insufficient contrast For more detailed information on setting up a healthy work environment, call NEC at (800) 820-1230, NEC FastFacts information at (630) 467-4363 and request ™...
640 x 480* at 60Hz to 75Hz 800 x 600* at 56Hz to 75Hz 832 x 624* at 75Hz 1024 x 768 at 60Hz to 75Hz ....NEC cites recommended resolution at 75 Hz for optimal display performance. Portrait: 480 x 640* at 60Hz to 75Hz...
VESA standard third party mounting arm or bracket. Allows for the monitor to be mounted on a wall or an arm using any third party compliant device. OSM Display Screen Copyright 1999 by NEC Technologies, Inc. 78134702.wpc 10/15/99, 2:00 PM...
”ghost” of that image remains, the monitor should be turned off for one hour to erase the image. NOTE: As with all personal display devices, NEC Technologies recommends using a screen saver at regular intervals whenever the screen is idle.
References • BBS (978) 742-8706 NEC Technologies’ Remote Bulletin Board System is an electronic service accessible with your system and a modem. Communication parameters are: 300/1200/2400/9600/14.4k/28.8k/33.6k bps, no parity, 8-data bits, 1 stop bit • Customer Service/ Technical Support (800) 632-4662 (978) 742-7049 •...
Limited Warranty NEC Technologies, Inc. (hereinafter “NECTECH”), warrants this Product to be free from defects in material and workmanship and, subject to the conditions set forth below, agrees to repair or replace (at NECTECH’s sole option) any part of the enclosed unit which proves defective for a period of three (3) years from the date of first consumer purchase.
TCO’99 Congratulations! You have just purchased a TCO’99 approved and labeled product! Your choice has provided you with a product developed for professional use. Your purchase has also contributed to reducing the burden on the environment and also to the further development of environmentally adapted electronics products.
Seite 20
TCO’99 cont. accumulative* processes. Flame retardants have been found in human blood and researchers fear that disturbances in foetus development may occur. TCO’99 demand requires that plastic components weighing more than 25 grams must not contain flame retardants with organically bound chlorine and bromine. Flame retardants are allowed in the printed circuit boards since no substitutes are available.
Council Directive 73/23/EEC: – EN 60950 Council Directive 89/336/EEC: – EN 55022 – EN 55024 – EN 61000-3-2 – EN 61000-3-3 and marked with NEC Home Electronics, LTD. 686-1, Nishioi Oi-Machi Ashigarakami-gun Kanagawa 258-8533, Japan 78134702.wpc 10/15/99, 2:00 PM...
AVERTISSEMENT AFIN D’ÉVITER TOUT RISQUE D’INCENDIE OU D’ÉLECTROCUTION, NE PAS EXPOSER CET APPAREIL À LA PLUIE OU À L’HUMIDITÉ. NE PAS UTILISER LA FICHE D’ALIMENTATION POLARISÉE AVEC UNE PRISE DE CORDON DE RALLONGE OU AUTRE PRISE SAUF SI LES BROCHES PEUVENT ÊTRE ENTIÈREMENT INTRODUITES. NE PAS OUVRIR LE BOÎTIER, LEQUEL CONTIENT DES COMPOSANTS À...
Contenu Votre produit peut être enregistré sur Internet à l’adresse http://www.nectech.com/productregistration La boîte* de votre nouveau moniteur NEC Technologies MultiSync ® de série LCD contient : • Moniteur MultiSync LCD 1510 avec socle inclinable, rotatif et pivotant • Cordon d'alimentation •...
OSM, consultez la section Commandes de ce guide. 7. Reportez-vous au manuel de l’utilisateur inclus avec CD du NEC LCD logicaiel d’installation pour l’installation et l’exploitation de ce logiciel. NOTA : En cas de problème, consultez la section Dépannage de ce manuel.
Seite 25
Mise en marche rapide (suite) Mini connecteur D-SUB à 15 Adaptateur broches Macintosh (non founi) Mini connecteur D-SUB à 15 Figure A.1 broches Figure B.1 L’attache A Bouton d’alimentation Figure C.1 Figure E.1 Figure D.1 Cordon d’alimentation 78134702.wpc 10/15/99, 2:00 PM...
Mise en marche rapide (suite) Lever et baisser l’écran du moniteur Il est possible de lever ou de baisser le moniteur en mode Portrait ou Paysage. Pour lever ou baissez l’écran, placez les mains de chaque côte du moniteur et soulevez ou abaissez à...
Seite 27
Mise en marche rapide (suite) Incliner et pivoter Placez les mains de chaque côté du moniteur et réglez l’inclinaison et la position souhaitées (Figure TS.1). Enlever le support du moniteur pour le montage Pour préparer le moniteur à différents types de montage : 1.
Commandes Les boutons de réglage OSM situés sur l’avant du moniteur fournissent les fonctions suivantes : Pour accéder au menu OSM, appuyez sur une des touches de commande ( ) ou sur la touche PROCEED ou EXIT). Pour basculer entre les modes Landscape et Portrait, appuyez sur la touche RESET.
Commandes (suite) (suite) • Pour désactiver le mode LOCK OUT, appuyez simultanément sur PROCCED et le bouton Réglage automatique AUTO Règle automatiquement la position de l’image, le format horizontal ou la résolution fine. Commandes de position POSITION H. Contrôle la position horizontale de l’image dans la zone d’affichage du LCD. POSITION V.
Seite 30
Commandes (suite) ALL RESET La sélection de ALL RESET vous permet de ramener tous les paramètres de commande OSM à leurs valeurs par défaut. Pour ramener les réglages individuels à leurs valeurs par défaut, il suffit de mettre en surbrillance la commande à...
Usage recommandé Consignes de sécurité et d’entretien POUR UN FONCTIONNEMENT OPTIMAL, PRIÈRE DE NOTER CE QUI SUIT POUR LE RÉGLAGE ET L'UTILISATION DU MONITEURS COULEUR MULTISYNC LCD : ® • NE PAS OUVRIR LE MONITEUR. Aucune pièce intérieure ne nécessite l'intervention de l'utilisateur, et l'ouverture ou la dépose des couvercles peut entraîner des risques de décharges électriques dangereuses ou d'autres risques.
Seite 32
Pour des informations plus détaillées sur l'établissement d'un environnement de travail sain, appeler NEC au (800) 820-1230, demander le service d’information par télécopieur NEC FastFacts au (630) 467-4363 et demander le document n 900108 ou écrire à...
800 x 600* @ 56 Hz à 85 Hz 832 x 624* @ 75 Hz 1 024 x 768 @ 60 Hz à 75 Hz ...... NEC recommande une résolution à 75 Hz pour des performances d'affichage optimales. Portrait : 480 x 640* @ 60Hz à...
MultiSync à n’importe quel autre bras ou baie de montage conforme VESA. Permet de monter le moniteur sur un mur ou un bras à l’aide de n’importe quel autre dispositif compatible. OSM Display Screen Copyright 1999 par NEC Technologies, Inc. 78134702.wpc...
«fantôme» de cette image, il faut mettre le moniteur hors tension pendant une heure pour effacer l’image. NOTA : Tout comme dans le cas des écrans personnels, NEC recommande l’utilisation d’un économiseur d’énergie à intervalles réguliers lorsque l’écran n’est pas utilisé.
Références • BBS (978) 742-8706 Le système de babillard électronique NEC Technologies est un service électronique accessible avec votre système et un modem. Les paramètres de communication sont : 300/1200/2400/9600/1,4 k/28,8 k bps, pas de parité, 8 bits de données, 1 bit d'arrêt •...
Garantie limitée NEC Technologies, Inc. (ci-après «NECTECH») garantit que ce produit est exempt de vice de fabrication et de main-d’oeuvre et, selon les conditions énoncées ci-dessous, accepte de réparer ou remplacer, à sa discrétion, toute pièce de l'appareil concerné qui s'avérerait défectueuse et ce, pendant une période de trois (3) ans à...
TCO’99 Félicitations! Vous avez acheté un produit qui répond à la directive TCO’99. En choisissant ce produit conçu pour une utilisation professionnelle, vous contribuez aussi à la réduction des effets nuisibles sur l’environnement et aussi au développement continu de produits électroniques respectueux de l’environnement.
Seite 39
TCO’99 (suite) 25 grammes ne contiennent pas de retardateurs de flame contenant du chlore ou du brome organiquement liés. Les retardateurs de flame sont autorisés dans les cartes à circuits imprimés étant donné qu’aucun substitut n’est encore disponible. Plomb** Le plomb peut être présent dans les tubes cathodiques, les écrans, les soudures et les condensateurs. Le plomb s’attaque au système nerveux et, à...
– EN 60950 la directive 89/336/EEC du Conseil : – EN 55022 – EN 55024 – EN 61000-3-2 – EN 61000-3-3 et porte le sigle NEC Home Electronics, LTD. 686-1, Nishioi Oi-Machi Ashigarakami-gun Kanagawa 258-8533, Japan 78134702.wpc 10/15/99, 2:00 PM...
FCC. MultiSync est une marque déposée de NEC Technologies, Inc. aux États-Unis et de NEC Home Electronics, Ltd. au Canada, au R.-U., en Allemagne, en France, en Espagne, en Italie, en Autriche, au Benelux, en Suisse, au Danemark, en Finlande et en Arabie Saoudite. Xtra View, AccuColor, et ErgoDesign sont des marques déposées de NEC Technologies, Inc.
WARNUNG UM BRÄNDE BZW. ELEKTRISCHE SCHLÄGE ZU VERMEIDEN, SETZEN SIE DIESES GERÄT WEDER REGEN NOCH SONSTIGER FEUCHTIGKEIT AUS. VERWENDEN SIE DEN GEPOLTEN STECKER DIESES GERÄTS NICHT MIT EINER VERLÄNGERUNGSSTECKDOSE ODER ANDEREN STECKDOSEN, WENN DIE POLE NICHT ZUR GÄNZE IN DIESE EINGEFÜHRT WERDEN KÖNNEN.
Monitor ™ 1510 mit Schwenk-/Kipp-/Drehfuß • Netzkabel • Wechselstromadapter (Nr.A1240T01) • Videosignalkabel • Benutzerhandbuch • NEC LCD Software, Pivot Software und andere nütz liche Dateien MultiSync LCD + Monitor mit 1510 Videosignalkabel und Wechselstromadapter Netzkabel Software-CD Benutzerhandbuch * Denken Sie daran, die Originalverpackung und das Verpackungsmaterial für einen späteren Transport bzw.
Signalkabels mit dem MultiSync Macintosh-Kabeladapter (Abbildung B.1). Ziehen Sie alle Schrauben fest. HINWEIS: Den MultiSync Macintosh-Kabel-Adapter können Sie bei NEC Technolo gies unter der Telefonnummer (800) 820-1230 bestellen. 3. Schließen Sie den 15-poligen Mini-D-SUB-Stecker des Videosignalkabels und des AC- Adapter-Kabels.
Quick Start / Fortsetzung Höher- und Tieferstellen des Monitorbildschirms Der Monitor kann sowohl in Längs- als auch in Querstellung höher- bzw. tiefergestellt werden. Um den Bildschirm höher-oder tieferzustellen, legen Sie Hände auf jede seite des Monitors und heben Sie an oder senken Sie zur gewünschten Höhe (Abbildung RL.1). Abbildung RL.1 Drehen des Bildschirms Bevor Sie den Bildschirm drehen, muß...
Quick Start / Fortsetzung Kippen und Schwenken Fassen Sie beide Seiten des Monitorbildschirms und kippen bzw. schwenken Sie den Bildschirm in die gewünschte Position (Abbildung TS.1). Abnehmen des Monitorfußes zu Montagezwecken Um den Monitor für alternative Montagemethoden vorzubereiten, gehen Sie vor wie folgt : 1.
Bedienungselemente Mit den vorne am Monitor befindlichen OSM- (On-Screen Manager)-Tasten werden die folgenden Funktionen ausgeführt : Um auf das OSM-Menü zuzugreifen, drücken Sie eine beliebige Steuertaste ( ) bzw. die Taste PROCEED oder EXIT. Um das OSM-Menü zwischen Längs- und Querformat umzustellen, drücken Sie die Taste RESET. Hauptmenü...
Bedienungselemente / Fortsetzung • Um die Funktion LOCK OUT zu deaktivieren, drücken Sie gleichzeitig die Tasten PROCEED und Auto Adjust AUTO Paßt die Einstellungen für Image Position, H. Size und Fine automatisch an. Positionsregler H. POSITION Steuert die horizontale Bildposition innerhalb des LCD-Anzeigebereichs. V.
Seite 50
Bedienungselemente / Fortsetzung ALL RESET Mit dieser Funktion können Sie alle OSM -Einstellungen auf die ™ Werkseinstellungen zurücksetzen. Einzelne Einstellungen können durch Hervorheben der Einstellung, die Sie zurücksetzen wollen, und anschließende Betätigung der RESET-Taste zurückgesetzt werden. Information Gibt Auskunft über die gegenwärtigen Einstellungen für die Anzeigeauflösung und die Auffrischfrequenz des Monitors.
Empfehlungen für die Verwendung Vorsichtsmaßnahmen und Wartung UM DIE OPTIMALE LEISTUNGSFÄHIGKEIT IHRES MULTISYNC LCD FARBMONITORS ZU GEWÄHRLEISTEN, SOLLTEN SIE BEI DER AUFSTELLUNG UND VERWENDUNG IHRES GERÄTES DIE FOLGENDEN PUNKTE BEACHTEN • ÖFFNEN SIE DEN MONITOR NICHT. Im Inneren des Gerätes befinden sich keine Teile, die vom Benutzer selbst gewartet werden können.
Seite 52
• Verwenden Sie die Primärfarbe Blau nicht vor einem dunklen Hintergrund, da sie schlecht zu sehen wäre und aufgrund des unzureichenden Kontrasts zu einer Überanstrengung der Augen führen könnte Nähere Informationen über die Einrichtung einer gesunden Arbeitsumgebung erhalten Sie, wenn Sie NEC unter der Telefonnummer (800) 820-1230 bzw. NEC FastFacts ™...
800 x 600* @ 56 Hz bis 85 Hz 832 x 624* @ 75 Hz 1024 x 768 @ 60 Hz bis 75 Hz ......Für optimale Darstellungsleitung des Monitors empfiehlt NEC eine Auflösung bei 75 Hz. Hoch: 480 x 640* @ 60Hz bis 76Hz...
VESA: Standardmontagevorrichtung: Damit kann der MultiSync Monitor an jedem standardmäßigen VESA-Montagearm oder Halter von Drittlieferanten montiert werden. So kann der Monitor unter Verwendung einer kompatiblen Montagevorrichtung eines Drittlieferanten an einer Wand oder an einem Tragarm montiert werden. OSM Display Screen Copyright 1999, NEC Technologies, Inc. 78134702.wpc 10/15/99, 2:00 PM...
Stunde lang auf dem Monitor angezeigt wurde und ein Schatten dieses Bildes auf dem Bildschirm verblieben ist, sollte der Monitor eine Stunde lang ausgeschaltet bleiben, um den Bildschatten zu beseitigen. ANMERKUNG: NEC Technologies empfiehlt, wie für alle persönlichen Anzeigegeräte, die regelmäßige Verwendung eines Screensavers, der sich einschaltet, wenn das angezeigte Bild länger unverändert bleibt.
Verweise • BBS (978) 742-8706 Das Remote Bulletin Board System von NEC Technologies ist ein elektronischer Service, den Sie mit Hilfe Ihres Systems und eines Modems nutzen können. Die Kommunikationsparameter lauten: 300/1200/2400/9600/14,4k/ 28,8k bps, keine Parität, 8 Datenbits, 1 Stopbit •...
Beschränkte Gewährleistung NEC Technologies, Inc. (nachstehend als „NECTECH“ bezeichnet) garantiert hiermit, daß dieses Produkt keinerlei Material- und Verarbeitungsfehler aufweist, und verpflichtet sich unter den nachstehenden Bedingungen dazu, innerhalb eines Zeitraums von drei (3) Jahren nach dem Datum des ersten Erwerbs durch einen Verbraucher jedweden Teil des gegenständlichen Produkts, der sich als defekt erweist, (nach...
Seite 58
TCO’99 Herzliche Gratulation! Sie haben gerade eines der unter TCO’99 zugelassenen und zertifizierten Produkte erworben. Damit steht lhnen ein Produkt zur Verfügung, das für die gewerbliche Anwendung entwickelt wurde. Ihr Kauf hat außerdem dazu beigetragen, die Umweltbelastung zu reduzieren und die weitere Entwicklung umweltgerechter Elektronikprodukte zu fördern.
TCO’99 Fortsetzung bioakkumulativer Prozesse* auch negative Auswirkungen auf die Vermehrung fischfressender Vögel und Säugetiere zu haben. Entflammungsverzögerer wurden auch im menschlichen Blut gefunden, und die Wissenschaftler fürchten, daß sie Störungen der fetalen Entwicklung zur Folge haben könnten. TCO’99 verlangt, daß Plastikkomponenten, die mehr als 25 Gramm wiegen, keine Entflammungsverzögerer mit organisch gebundenem Chlor oder Brom enthalten dürfen.
Richtlinie des Rates 73/23/EEC: – EN 60950 Richtlinie des Rates 89/336/EEC: – EN 55022 – EN 55024 – EN 61000-3-2 – EN 61000-3-3 und folgende Kennzeichnung trägt NEC Home Electronics, LTD. 686-1, Nishioi Oi-Machi Ashigarakami-gun Kanagawa 258-8533, Japan 78134702.wpc 10/15/99, 2:00 PM...
Wir erklären hiermit, daß die obengenannte Ausrüstung den in den FCC-Bestimmungen enthaltenen technischen Standards entspricht. MultiSync ist ein eingetragenes Warenzeichen der Firma NEC Technologies, Inc. in den U.S.A. und der Firma NEC Home Electronics, Ltd. in Kanada, Großbritannien, Deutschland, Frankreich, Spanien, Italien, Österreich, den Benelux-Staaten, der Schweiz, Dänemark, Finnland, Norwegen und Saudi-Arabien.
FCC Rules. MultiSync is a registered trademark of NEC Technologies, Inc. in the U.S. and of NEC Home Electronics, Ltd. in Canada, UK, Germany, France, Spain, Italy, Austria, Benelux, Switzerland, Denmark, Finland, Norway and Saudi Arabia. XtraView, AccuColor and ErgoDesign are registered trademarks of NEC Technologies, Inc.
