Fig. 5
version and number:
Any powering up the instrument includes a check of the electronics and
an Autozero. Prior to this the lamp is heated to the working temperature
for about 20 seconds indicated by the following display:
signal:
♦λ:254
t: 1
The start routine will be finished by an automatically Autozero. Now
the Filter-Photometer is ready to work, showing the display:
signal:
0.0000
♦λ:254
t: 1
Operating the Filter Photometer
Internal Software Structure
The software is divided in various menus, each of which allows
particular settings and operational modes. You reach the single menus
by positioning the cursor on the rhombus field
the ∆ or ∇ keys. As indicated in Abb. 5, the menus will be called up in
an endless loop.
The single menus will be described in detail. Inside of any menu the
cursor can be moved to the next or predecessing field using the
⊲ or ⊳ keys respectively. There it is possible to increase or decrease
the corresponding parameter settings by help of the ∆ or ∇ keys. In
some cases you can scroll with the ∆ or ∇ keys through the available
options. Moving to an other entry field using the ⊲ or ⊳ keys
respectively the entered changes will be confirmed.
signal:
0.0000
?λ:254
t: 1
INT
sig:0.6543
?1/8
ref:0.3848
Menu sequence of the UV Monitor C-630
The SIGNAL menu
Büchi UV Monitor C-630
-.----
HEA
GLP
?01
ANALOG OUT: [au]
?full
♦
followed by pressing
S/N:00047755
00962.0h 101
scale:2e-0
