SPECIFICATIONS
PRODUCT DIMENSIONS: 164 x 108.5 x 23.6 mm / 6.46" x 4.27" x 0.93"
PACKAGED DIMENSIONS: 357 x 153.5 x 85 mm / 14" x 6.04" x 3.35"
PRODUCT WEIGHT: 330g / 0.73 lb
PACKAGED WEIGHT: 0.8kg / 1.76 lb
CONSTRUCTION MATERIAL: Metal
COLOUR: White
TECHNICAL DETAILS:
Input and Output TMDS Signal: 0.7-1.5 volts p-p
Input and Output DDC Signal: 5 volts p-p (TTL)
Maximum Video Format Supported: 4K
Output Video: HDMI 2.0 with HDCP 2.2
Output Audio: PCM
Compression: H.264
Input and Output HDMI Cable Length: 5m (16.4 ft) AWG 26
Operating Temperature Range: 0-50°C
Storage Temperature Range: -10-70°C
Operating Humidity Range: 0 to 90 % no condensation
Tx Power Consumption: 7 watts
Rx Power Consumption: 10 watts
CAT6 Maximum distance (if connected peer-to-peer directly): 120 m (394 ft)
IR Passback Bandwidth: 20-60 kHz
ESD protection: 1a Contact discharge level 3 / 1b Air discharge level 3 (Standard: IEC61000-4-
2)
CONNECTIVITY:
1 x HDMI (type A)
1 x Ethernet (RJ45)
1 x DC Power (2-port phoenix)
1 x 3.5mm Minijack (IR)
POWER SUPPLY: 100-240v 50/60Hz AC 5 volt / 3 amp
Transformer integrated into plug. Includes interchangeable plugs: UK/EU/US/AU. DC tail length:
1.8m. Transformer dimensions: 81 x 52 x 38mm / 3.2" x 2.05" x 1.5"
ACCESSORIES INCLUDED:
2 x Mounting ears
1 x Remote Control
1 x IR Emitter Cable
1 x IR Receiver Cable
WARRANTY: Lifetime return-to-base
http://www.visionaudiovisual.com/support
COMPLIANCES: RoHS, WEEE, CE/EMC
ORDER PART CODE:
Transmitter TC-MATRIXTx [EU SAP: 4631209 / US SAP: 4631209]
Receiver TC-MATRIXRx [EU SAP: 4631210 / US SAP: 13293566]
18
TC-MATRIX_manual_en.doc
