2. CONNECT ALL TX AND RX DEVICES TO NETWORK All devices must be on same subnet.
Microwave extenders may not have enough bandwidth to support this product which uses
up to 24Mbps transmitting 4K 60 Hz video
3. CONNECT SOURCES TO TX AND DISPLAYS TO RX One Tx for each source, one Rx for each
display. Uses proprietary encoding and cannot decode a stream from another product or
VLC.
4. SET CHANNEL ID ON ALL DEVICES
a. All Tx should be on different channels.
b. All Rx should be on different channels.
5. SET "TX CONNECTED" CHANNEL ON RECEIVERS The source connected to the Tx selected
will show on the display. Allow a few seconds for the HDCP handshake.
Set to Forwarding
