Kathrein UFO compact Bedienungsanleitung Seite 12

17/7 ERE 02
Programming using the controller UFG 300 *
1 Explanation of the keypad
The controller's power supply comes via the module or from a
controller bus demultiplexer UFX 312 or UFX 314 if used.
2 Operating instructions
The parameter currently selected with the
The desired value is set in steps using the
Select or exit a sub-menu using the
On the display, the symbol
If the controller is disconnected from the UFO
the settings originally stored in the module are restored.
Note:
The module-specifi c setting instructions are included with the instructions for the respective UFO
Note:
The instructions include stickers with button explanations in English, French and Spanish.
These can be applied over the German stickers on the back of the device.
Increase value
Decrease value
Next parameter
Previous parameter
Next channel unit
Previous channel unit
Sub-menu
Save all parameter
values
and buttons fl ashes on the display.
and buttons or by entering alphanumeric characters (see section 3).
button.
fl ashes if there is a sub-menu available for the selected parameter.
® compact module without saving the settings by pressing the
Order numbers for the accessories that are illustrated:
ERE 01 274854
ERE 02 274855
EMU 02 273245
UFZ 300 20610070
Screw the ERE 02 to the loop-through output on the splitter
and connect it to the Sat IF input on the twin module using
F-type angled connectors (m) EMU 02 and the F-type
connecting cable that is freed
* Not included
Help text for the currently selected parameter
Move the cursor to the left in alphanumeric
entry mode
Change editing mode:
1 st press -
nd
2 press -
System menu:
Switch to the alpha-
numeric entry mode
Apply the entry and
leave the alphanumeric
entry mode
- Language setting
- Display the software versions for
the controller and channel unit
- Special functions (cable-NIT)
button,
®
compact module.
