5.5 Anschlussstecker

5.5.1 D-Sub Stecker

5.5.2 Schraubenklemmen
No.1
Distanz Laser Sensor
Pin Designator
1 Rx
2 Tx
3 T-
4 T+
5 R-
6 R+
7 PWR
8 PWR
9 DO 1
10 DO 2
11 DO E
12 AGND
13 AO
14 GND
15 GND
Pin Designator
1 R+
2 R-
3 T+
4 T-
5 Tx
6 Rx
7 AGND
8 AO
9 DO E
10 DO 2
11 DO 1
12 GND
13 PWR
V1.05de
Beschreibung
RS232 receive line
RS232 send line
RS422 send line negative
RS422 send line positive
RS422 receive line negative
RS422 receive line positive
Stromversorgung DC
+ 9V...+30V DLS-A
+24V...+30V DLS-AH (Heizungsoption)
Digitaler Ausgang 1 (Open Drain)
Digitaler Ausgang 2 (Open Drain)
Digitaler Ausgang Gerätestörung (Open Drain)
Analoger Ground
Analoger Ausgang (0/4..20mA)
Geräte Ground
Geräte Ground
Beschreibung
RS422 Receive line positive
RS422 Receive line negative
RS422 Send line positive
RS422 Send line negative
RS232 Transmit line
RS232 Receive line
Analoger Ground
Analoger Ausgang (0/4..20mA)
Digitaler Ausgang Gerätestörung (Open Drain)
Digitaler Ausgang 2 (Open Drain)
Digitaler Ausgang 1 (Open Drain)
Geräte Ground
Stromversorgung DC
+ 9V...+30V DLS-A
+24V...+30V DLS-AH (Heizungsoption)
